2. Technical Specifications

Specifications
Electrical Characteristics
Power supply type
Operating voltage range
Input current standby (12VDC)
Input current max (16VDC)
LED control input
Tamper output
Cable distance to host
controller
Max proximity card read
range*
Proximity card modulation
Proximity card compatibility
Card Transmit format (Reader)
Keypad Transmit Format
(Reader)
LED indicators
Communication
Page 7
AYC- F/G/M60
Linear type – recommended
5 - 16VDC (when used as a controller,
provided by the secure application
appurtenance)
105mA
140mA
Dry contact N.O.
Open collector, active low, 32mA max
sink current
Up to 500ft (150 meters) using an
18AWG cable
1.77 inches (45mm)
ASK/FSK at 125 KHz
EM/HID cards
26-bit Wiegand, or Clock & Data
Programmable PIN code formats
Two tri-colored LEDs
Data1/C1, Data0/C2—open collector,
5V termination
