Programming Menu

Default Factory Settings are marked by a "*" sign.
Menu Description
1 Selecting Keypad Transmission Format
Single Key, 6-Bit Wiegand (Rosslare Format)
Single Key, 6-Bit Wiegand with Nibble + Parity Bits
Single Key, 8-Bit Wiegand, Nibbles Complemented
4 Keys Binary + Facility Code, 26-Bit Wiegand
1 to 5 Keys + Facility Code, 26-Bit Wiegand
6 Keys BCD and Parity Bits, 26-Bit Wiegand
Single Key, 3x4 Matrix Keypad
1 to 8 Keys BCD, Clock & Data
Single key, 4-bit Wiegand
2 Selecting Card Transmission Format
26-Bit Wiegand
Clock & Data
Wiegand Card + PIN
3 Changing the Programming Code
4 Changing the Facility Code
6 Setting the Backlight
always off
always on
10 sec. backlight after key press otherwise off
10 sec. backlight after key press otherwise dimmed
Setting Reader Format
ASK
FSK
ASK + FSK
0 Return to Factory Default Settings
Page 15 AYC-Qx4
family
Default
*
*
1234
0
*
