Fig. 12: Rating label for a heating thermo-
stat (example)
Specification
SCCR:
Compressor FLA I:
Compressor HP I:
Compressor FLA II:
Compressor HP II:
Pump FLA I:
Pump HP I:
Pump FLA II:
Pump HP II:
Refrigeration fan FLA:
Refrigeration fan HP:
30 / 156
Description
Indicates the short-circuit current according to NEC 110-10
or UL508A which the components and assemblies used in the
machine can withstand
Current consumption of Compressor I under full load
Power of Compressor I in horse power
Current consumption of Compressor II under full load
Power of Compressor II in horse power
Current consumption of Pump I under full load
Power of Pump I in horse power
Current consumption of Pump II under full load
Power of Pump II in horse power
Current consumption of the fan under full load
Power of the fan in horse power
Values (HP and FLA) for the compressor, pump and refrigeration
fan are only provided on the rating label for components with a per-
formance class over 0.75 HP. For components with a performance
class under 0.75 HP, no values (HP and FLA) are provided on the
rating label.
