Type Key; Scope Of Delivery; Functions; Application/Use - Wilo -Drain TS Installation And Operating Instructions Manual

Operating mode, immersed
Operating mode, non-immersed
Fluid temperature
Fluid temperature, short-term for
3 min
Max. immersion depth
Protection class
Insulation class
Max. switching frequency
Key
1)
In accordance with ISO 8601
2)
2.5 min operation/7.5 min standby
2.3

Type key

Ex-
Drain TSW 32/8-A/B 10M KA
ample:
TS Series
W Version:
• TS = without twister function
• TSW = with twister function
32 Nominal diameter of discharge connection
8 Max. delivery head in m
A Version with float switch and plug
B Version number
10M KA Connection cable length
2.4

Scope of delivery

• Pump
• Swing check valve, pre-assembled
• Hose connection, enclosed
• Installation and operating instructions
2.5

Functions

2.5.1 Self-switching thermal motor monitoring
If the motor becomes too hot, the pump is deactivated. After the
motor has cooled down, the pump is automatically switched on
again.
2.5.2 Float switch
The pump is equipped with a float switch. The float switch is used
to switch the pump on and off depending on the level:
• Upper floater: Pump on
• Lower floater: Pump off
3

Application/use

3.1

Intended use

For the pumping in domestic areas of:
• Sewage not containing faeces
–
Wash basins
–
Shower basins/bathtubs
–
Washing machines
• Wastewater (with small amounts of sand and gravel)
–
Rainwater
–
Drainage water
• Fluid temperature: 3 ... +40 °C (37 ... 104 °F), max. 90 °C (194 °F)
for 3 minutes
Installation and operating instructions • Wilo-Drain TS/TSW 32 • Ed.01/2022-07
S1
2)
S3 25%
3 ... +40 °C (37 ... 104 °F)
90 °C (194 °F)
3 m (10 ft)
IP68
F
50/h
Use inside and outside buildings
• The pump must have a connection cable of at least 10 metres if
it is to be used outside a building.
• If the connection cable is shorter than 10 metres, the pump
must be used inside a building!
3.2

Improper use

DANGER
Explosion due to pumping of explosive fluids!
Pumping of highly flammable and explosive fluids
(gasoline, kerosene, etc.) in pure form is strictly pro-
hibited. There is a risk of fatal injury due to explo-
sion! The pumps are not designed for these fluids.
The submersible pumps must not be used for pumping:
• Untreated sewage
• Sewage containing faeces
• Drinking water
• Fluids containing hard components (such as stones, wood,
metal, etc.)
• Fluids containing high quantities of abrasive contents (e.g.
sand, gravel).
• Viscous fluids (e.g. oil and grease)
• Seawater
Intended use also includes compliance with this manual. Any other
use is regarded as non-compliant with intended use.
4

Transport and storage

CAUTION
Soaked packaging may tear!
The product may fall on the ground if unprotected
and may be damaged. Lift wet packaging carefully
and replace it immediately!
• Wear protective equipment!
• Carry the pump by the handle. Never carry or pull on the con-
nection cable!
• Clean the pump and disinfect if necessary.
• Close the discharge connection.
• Protect the connection cable against kinking and damage.
• Use original packaging for transport and storage.
• Pack the pump when dry. Wet or humid pumps may soften the
packaging.
• Storage conditions:
–
Maximum: -15 ... +60 °C (5 ... 140 °F), max. humidity: 90 %,
non-condensing
–
Recommended: 5 ... 25 °C (41 ... 77 °F), relative humidity:
40 ... 50 %
5

Installation and electrical connection

5.1

Installation types

Installation type
Stationary wet well
en
Wilo-Drain ...
TS ... TSW ...
• •
