Wiring Diagram - Directed DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
(+) Accessory: Pin 3
D2D Port
(-) Ground
(+) 12V Input
(-) Hood Status Input
(+) Ignition Input/Output
(AC) Tach Input
(-) Parking Lights Output
(-) Parking Lights: Pin 3, 5 or 7
Refer to the
Vehicle
connections
section for the
1 2 3 4 5 6
corresponding
7 8 9 10 11 12
connector, pin
and wire color
of your vehicle.
Headlight Switch
(black 12-pin connector)
10 403.GM10 4.27 2016 Buick Verano
©2022 VOXX•DEI LLC. All rights reserved.
Ignition Switch
(black or white connector)
1 2 3 4 5 6
(+) 12V: Pin 2
(+) Ignition: Pin 1
(+) 12V
(-) Hood Pin
1 2 3
Immo.
Data: pin 2
Cut
Immobilizer
Control
Module
(violet 3-pin
(-) Driver
connector
Door Trigger
below ignition
Refer to the
switch)
Vehicle
connections
section for the
corresponding
connector, pin
and wire color
of your vehicle.
OBDII Diagnostic
(connector side view)
SW CAN: Green, pin 1
HS CAN High:
Tan/Black or Blue
pin 6
1 8
9 16
HS CAN Low:
Tan or White
pin 14
Immo. Data Interrupt (connector side): Orange/Red: 10
Immo. Data Interrupt (vehicle side): Yellow/Red: 11
(-) RAP Off Output: Green/Black: 2
(AC) Tach Output: Violet/White: 5
(+) Accessory Output: Gray/Black: 7
(MUX) Clutch Output: Violet/Green: 8
(MUX) Clutch Output: Violet/Brown: 9
Immo. Data (vehicle side): Orange/Black: 11
Clutch: Yellow, pin B
ONLY required for
manual transmission
A B C
applications.
Clutch Switch
(black 3-pin connector)
Single Wire CAN: Lt. Green: 1
HS CAN High: Tan/Black: 3
HS CAN Low: Tan: 4
(+) 12V Input: Brown: 7
(+) Ignition Output: Yellow: 8
).
