Module Programming - Directed DB3 Installation Manual

Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Wait until the LED turns ON solid red.
1
Note: To skip the transponder programming and use convenience features only, press the
programming button 5 times. Wait until the LED turns ON solid orange for 3 seconds, then
proceed to step 2.
Press Unlock on the OEM remote or the door to wake up the CAN bus. The LED starts
flashing orange quickly.
2
If the transponder programming was skipped, the LED turns ON solid orange for 3 seconds,
then turns OFF when programming is completed.
Insert and turn the key to the ON position, then leave it there for 5 seconds. The LED starts
3
flashing green quickly.
Turn the key to OFF and remove it from the ignition barrel. The LED will keep flashing green
4
quickly.
Important! This operation must happen within 5 seconds.
5
Insert the key back into the ignition barrel. The LED keeps flashing green quickly.
Turn the key to the ON and leave it there. Within 15 seconds, the LED will start flashing
6
orange slowly.
When the LED starts flashing orange slowly, turn the ignition OFF, remove the module from
7
the vehicle, and reconnect it to your computer. The web site will automatically recognize that
you are moving onto the second phase of the programming sequence.
8
Click on Submit Key2GO Request.
Once the configuration is completed, reconnect the module. The LED turns ON solid green for
9
3 seconds, then shuts OFF.
You have successfully completed the module programming sequence.
14
403.GM10 4.27 2016 Buick Verano
