Wiring diagram with T-Harness (THGM610D Rev. 1 & 2)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Ignition Barrel
To
To
Vehicle
Ignition
(violet connector
Ignition Switch
(black or white
connector)
T-01
3-pin
connectors
T-02
NOT USED
(AC) Tach Input
(+) Ignition Input/Output
(-) Parking Lights Output
(+) 12V Input
(-) Ground
D2D Port
8 403.GM10 4.27 2016 Buick Verano
©2022 VOXX•DEI LLC. All rights reserved.
Use connectors
labeled GM10
GM 10 GM 10
3-pin
To
connectors
Immobilizer Away from
Control Module Immobilizer
Control Module
under ignition (vehicle side)
switch)
THGM610D Rev. 1 & 2 (Optional T-Harness)
(+) 12V
(-) Parking Lights: Pin 3, 5 or 7
Refer to the
Vehicle
connections
section for the
1 2 3 4 5 6
corresponding
7 8 9 10 11 12
connector, pin
and wire color
of your vehicle.
Headlight Switch
(black 12-pin connector)
4-pin
White
Connector
Cut away the 4-pin
connector and connect
the three wires to the
OBDll 16-pin connector.
Cut
HS CAN High: Tan/Black
SW CAN: Lt. Green
HS CAN Low: Tan
NOT USED
(AC) Tach Output: Violet/White
(+) Ignition Input: Pink
(MUX) Clutch Output: Violet/Green
(MUX) Clutch Output: Violet/Brown
(-) RAP Off Output: Green/Black
Clutch: Yellow, pin B
A B C
Clutch Switch
Refer to the Vehicle
(black 3-pin connector)
connections section for
the corresponding
ONLY required for connector, pin and wire
color of your vehicle.
manual transmission
applications.
OBDII Diagnostic
(connector side view)
HS CAN High: Pin 6
SW CAN: Pin 1
1 8
9 16
HS CAN Low: Pin 14
Hood Pin
Note: The Hood Pin is only required
(-) Driver's Door Trigger
on vehicles that are not equipped
with a factory hood pin.
Remote Start Safety
Override Switch
).
D2D
only
Do not
connect
XKD2D65
