2.1 CASTER WHEEL ASSEMBLY - TAIL/WING
TAIL CASTER WHEEL ASSEMBLY - TAGGED
(61-081-010)
6 7
5
A
5
1
(6) 9/16 - 18 UNF
WHEEL NUTS
ITEM PART NUMBER
1 61-080-009
2 61-080-013
3 61-080-006
4 05-51081-01
5 61-050-003
6 48-090592
7 66-010250
STEP 1
The caster wheel assembly comes pre-assembled from the factory.
45' Rotary Harrow
2
4
CASTER SWIVEL, H.D.
CASTER MOUNT BRKT TAIL
CASTER MOUNT BRKT WING
TIRE AND RIM ASSY
CASTER BUSHING, H.D.
CAPSCREW, 1/2 X 1 1/4 G5 PLT
LOCKWASHER, 1/2
WING CASTER WHEEL ASSEMBLY
(61-082-009) (2 per Unit)
3
DESCRIPTION
7
QTY
1
1
1
1
2
2
2
SEPT 2008
