- Page 1 69-SERIES OPERATOR’S MANUAL THIS MANUAL TO ACCOMPANY MACHINE PART NO. 69-OM-01 PRINTING DATE: DEC 2013...
- Page 2 WARRANTY POLICY KELLEY MANUFACTURING COMPANY (KMC) warrants that all goods sold to the original purchaser of any KMC product shall be free of any defects in material and workmanship if used under normal operating conditions. warranty period begins on the date of purchase by the retail customer and ends twelve (12) months thereafter.
-
Page 3: Table Of Contents
6900 SERIES SUBSOILER LEVELER OWNERS MANUAL Table of Contents: FORWARD Introduction ···························································································· 3 To the Purchaser ······················································································ 3 Models Covered in This Owner’s Manual······················································· 4-5 Pre-Operational Check List ········································································ 6 SAFETY Symbol Information ·················································································· 7 Safety Decals ··························································································· 8 Retail Customers Responsibility under the KMC Warranty ······························· 9 Safety Procedures ·····················································································... - Page 4 Residue Cutting Options: Front Swivel Coulter ············································································ 22 Cover Crop Roller ··············································································· 22 Ripper Tool Options: Reset on the Go Shank ·········································································· 23 Toggle Shank ····················································································· 23 Finishing Tool Attachment: Spiked Roller ····················································································· 24 Spiked Roller Scraper (optional) ····························································· 25 OPERATIONAL SET-UP Tractor Preparation: Front End Weights ··············································································...
-
Page 5: Forward
FORWARD INTRODUCTION: The 6900 Series Subsoiler Leveler is a heavy-duty deep tillage tool that is capable of breaking up the ground hardpan across the entire width of the implement while leveling the soil surface in heavy residue conditions. The unit comes equipped with Residue Cutting Coulters, whether on individual Front Swivel Coulter Mounts or attached directly to a Cover Crop Roller. -
Page 6: Models Covered In This Owner's Manual
MODELS COVERED IN THIS OWNER’S MANUAL: Subsoiler Leveler With Reset On The Go & Front Swivel Coulter MODEL NUMBERS 69-07-R-FC 69-09-R-FC 69-11-R-FC 69-13-R-FC Subsoiler Leveler With Reset On The Go & Cover Crop Roller MODEL NUMBERS 69-07-R-CR 69-09-R-CR 69-11-R-CR 69-13-R-CR... - Page 7 Subsoiler Leveler With Toggle Trip Shanks & Front Swivel Coulter MODEL NUMBERS 69-07-T-FC 69-09-T-FC 69-11-T-FC 69-13-T-FC Subsoiler Leveler With Toggle Trip Shanks & Cover Crop Roller MODEL NUMBERS 69-07-T-CR 69-09-T-CR 69-11-T-CR 69-13-T-CR...
-
Page 8: Pre-Operational Checklist
PRE-OPERATIONAL CHECKLIST: All safety and operating procedures reviewed All hardware checked for tightness Hitch connection to implement information reviewed Field adjustment procedures reviewed Lubrication information reviewed Machine fully lubricated Warranty information reviewed... -
Page 9: Safety
SAFETY SYMBOL INFORMATION This safety alert symbol is used throughout this manual to identify safety messages. When you see this symbol, read the message which follows as it will advise you of possible injury. REMEMBER THINK SAFETY! (RED) This symbol indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury. -
Page 10: Safety Decals
SAFETY DECALS The Safety decals that follow are associated with the implement covered in this owner’s manual. They should be reviewed and associated with where they are applicable on the implement being covered. -
Page 11: Retail Customers Responsibility Under The Kmc Warranty
RETAIL CUSTOMERS RESPONSIBILITY UNDER THE KMC WARRANTY: The retail customer’s responsibilities are: 1. To read the Operator’s Manual and operate the Subsoiler Leveler in accordance with the instructions given in this manual. 2. To inspect the Subsoiler Leveler daily, lubricate as specified and repair or replace parts as needed, especially when continued use would cause damage or excessive wear to other parts. - Page 12 5. Do not allow children to operate the Subsoiler Leveler. Only experienced tractor operators should operate the tractor when using the Subsoiler Leveler. 6. Stay clear of hydraulic lines, as they maybe under extreme pressure or heat. 7. Drive safely during transport; excessive speed while turning or on rough ground could cause damage to the Subsoiler Leveler and/or cause the tractor to tip over.
-
Page 13: Assembly Set-Up
ASSEMBLY SET-UP GENERAL: Most of the general set-up and assembly for your KMC Subsoiler Leveler has been performed at the factory. Those items not installed at KMC will be reviewed later in this section. For your conven- ience, please see the “Overhead Layouts” portion of this section, to ensure proper positioning for the size and configuration of your KMC Subsoiler Leveler. - Page 14 WARNING CARE SHOULD BE TAKEN DURING SET-UP AND ASSEMBLY OF THIS PRODUCT. DEATH OR SERIOUS INJURY COULD OCCUR IF PROPER STEPS ARE NOT TAKEN TO FULLY SECURE THE UNIT WHEN WORKING UNDERNEATH IT. FOR YOUR SAFETY, ENSURE THE UNIT IS PROPERLY SUPPORTED BY LOWERING THE JACKSTAND SUPPORTS THAT HAVE COME ASSEMBLED WITH IT, OR PROPERLY SECURE THE UNIT WITH ANY HOISTING DEVICES BEFORE ATTEMPTING ANY FURTHER SET-UP...
-
Page 15: Bolt Torque Chart
! IMPORTANT ! Before set-up and assembly can be completed ensure that all hardware is in place and fully tightened. Refer to the Bolt Torque Chart below for proper torque values. BOLT TORQUE CHART SAE GRADE 5 SAE GRADE 8... -
Page 16: Overhead Layouts
OVERHEAD LAYOUTS:... -
Page 24: Residue Cutting Options
RESIDUE CUTTING OPTIONS: Front Swivel Coulters: If equipped with Front Swivel Coulters on the unit, the coulter arm assemblies will be pre- mounted to the bar (verify pre-mount location using the “Overhead Layout” portion of this section) and it may be necessary to mount the coulter blades to the coulter arm assemblies. -
Page 25: Ripper Tool Options
RIPPER TOOL OPTIONS: Toggle Trip Shanks Reset-On-The-Go Shanks SHANK WEAR SHIN SHANK WEAR SHIN 5/16 X 1 3/8 ROLL PINS 5/16 X 1 3/8 ROLL PINS RIPPER POINTS RIPPER POINTS 3/8 X 1 1/4 ROLL PIN 3/8 X 1 1/4 ROLL PIN The 6900 Series Subsoiler Leveler comes equipped with a choice of the Reset on the Go Ripper Shank or the Toggle Trip Shank. -
Page 26: Spiked Roller
FINSHING TOOL ATTACHMENT: Spiked Roller ITEM DESCRIPTION PART NUMBER ITEM PART NUMBER DESCRIPTION RATCHET ASSY 22-050-024 48-100550 CAPSCREW, 1X4-1/2 NC HX HD GD 5 PLT 22-050-024 RATCHET ASSEMBLY CAPSCREW, 1X6 NC HX HD GD 5 PLT 48-100615 LOCKNUT, 1" NC STOVER GD B PLT 72-020125 48-100550 CAPSCREW, 1 X 4 1/2 G5 PLT... -
Page 27: Spiked Roller Scraper (Optional)
Spiked Roller Scrapper (OPTIONAL) ITEM PART NUMBER DESCRIPTION Parts List 68-010250 HEXNUT, 1/2 PLT ITEM PART NUMBER DESCRIPTION HEXNUT, 1/2 PLT 68-010250 66-010250 LOCKWASHER, 1/2 REG PLT LOCKWASHER, 1/2" REGULAR PLT 66-010250 62-010100 FLATWASHER, 3/8 STD PLT 62-010100 FLATWASHER, 3/8" STANDARD PLT 66-010150 LOCKWASHER, 3/8 PLT LOCKWASHER, 3/8 PLT... -
Page 28: Operational Setup
OPERATIONAL SETUP TRACTOR PREPARATION: Before operating implement refer to tractor operator’s manual for information concerning safe methods of operation, hydraulics, hitch adjustment, tire inflation, wheel adjustments and tractor weights. Check tractor brakes and warning lights, make sure they are in proper working order. Check tractor hydraulics oil reservoir and add oil if needed. -
Page 29: Hitching To The Implement
HITCHING TO THE IMPLEMENT ! IMPORTANT ! WARRANTY NOTE: Use of articulated four-wheel drive or track tractors with 3 point lift im- plements voids the warranty on the toolbar main frame. Sudden turns or steering corrections made by these types of tractors, when the implement is in the ground, can exert extreme forces through the implement’s frame and/or shank components and cause unwarranted fatigue/failure. -
Page 30: Tractor Hook-Up
Tractor Hook-Up DANGER DO NOT STAND BETWEEN TRACTOR AND IMPLEMENT DURING HITCHING. ITEM DESCRIPTION PART NUMBER 7-SHANK STEP HITCH PIN, LONG PLT 05-026-008 TOOLBAR KLIK PIN, 7/16 X 1 3/4 02-050-002 CAPSCREW, 1 X 6 G8 PLN 48-200450 HEXNUT, 1 PLT 68-010450 LOCKWASHER, 1 PLT 66-010450... - Page 31 ITEM DESCRIPTION PART NUMBER PIN, MAST 06-081-018 KLIK PIN, 7/16 X 2 03-050-094 STEP HITCH PIN, LONG PLT 05-026-008 KLIK PIN, 7/16 X 1 3/4 02-050-002 CAT II QUICK COUPLER QC hooks pin in lower mast hole QC against inside of lower hitches ...
- Page 32 9-SHANK TOOLBAR ITEM DESCRIPTION PART NUMBER PIN, MAST 06-081-018 KLIK PIN, 7/16 X 2 03-050-094 SPACER, CAT III 05-024-010 PIN, CAT III-IIN HITCH 16-080-316 CAT III 3-POINT HITCH Top link pin in top mast hole Lower links against out- side of lower hitch ...
- Page 33 11-SHANK 13-SHANK ITEM DESCRIPTION PART NUMBER TOOLBARS PIN, MAST 06-081-018 KLIK PIN, 7/16 X 2 03-050-094 KLIK PIN, 7/16 X 2 3/4 16-050-094 SPACER, CAT III 05-024-010 BUSHING, CAT III LOWER HITCH 16-024-259 PIN, LOWER HITCH CAT III 16-026-102 ROLL PIN, 1/2 X 3 1/2 PLN 12-050-001 CAT III 3-POINT HITCH ...
- Page 34 ITEM DESCRIPTION PART NUMBER KLIK PIN, 7/16 X 2 03-050-094 PIN, CAT IV MAST 67-080-028 PIN ASSY, CAT IV HITCH 67-081-001 KLIK PIN, 7/16 X 2 3/4 16-050-094 CAT IV NARROW QUICK COUPLER QC hooks pin in top mast hole ...
-
Page 35: Leveling Implement Tool Bar
LEVELING IMPLEMENT TOOL BAR For best results, when leveling the implement, position the tractor with implement on a level floor. Check tractor tire pressure and inflate equally from side to side. See your tractor operator’s manual for correct tire inflation pressure. Leveling Side To Side "B"... -
Page 36: Implement Preparation Ripper Shank Tools
IMPLEMENT PREPARATION Ripper Shank Tools Tripped Shank Clearances It is common practice to mount aftermarket equipment on a KMC toolbar, such as fertilizer tanks or aftermarket row markers. It is critical that all aftermarket equipment is located properly on the toolbar so that it will not interfere with the reset mechanism on the ripper shanks. -
Page 37: Toggle Trip Shank
Toggle Trip Shank The Toggle Trip ripper shank is designed to trip when the shank encounters an immovable obstacle. The trip link will flex causing the center pin to rise and the shank to pivot vertically rearward, up and over the obstacle. To reset the Toggle Trip ripper shank, the toolbar should be lifted until the ripper points on all shanks are above the ground. -
Page 38: Depth Of Penetration
Depth of Penetration The purpose of a deep tillage tool is to fracture the compacted layer of soil beneath the surface known as the hardpan. The hardpan, usually only a couple inches thick, prevents plant roots from reaching moisture and nutrients below. The deep tillage tool is designed to run 1”-2”... -
Page 39: Front Coulter Adjustment
Front Coulter Adjustment Front coulters are set at the factory to be directly aligned with the ripper shanks. This is important for smooth residue flow around the shank. If the coulter is not properly aligned, loosen the 3/4in hardware on the U-bolt and slide the mount bracket over until the coulter is aligned. Retighten according to the torque specification chart in the “General”... -
Page 40: Cover Crop Roller Adjustment
Cover Crop Roller Adjustments The height of the Cover Crop Roller (CCR) is determined by the position of the 7/8in adjustment bolt. To adjust the height of the CCR, pull the shanks into the soil until the weight of the roller is supported by the ground. -
Page 41: Spiked Roller Adjustment
Spiked Roller Adjustments The spiked roller on the back of the Subsoiler Leveler is used to gauge the working depth of the shank. Any adjustments done to the height of the spiked roller will directly affect the depth at which the shank penetrates the ground. -
Page 42: Start-Up
START-UP Before initial operation of this piece of equipment, review the “Pre-Operational Checklist” at the front of this manual. Make sure all fields of the checklist have been performed and make any notes necessary for future operators. Your piece of equipment should now be ready for field operation. NOTES:... -
Page 43: Service Schedule
MAINTENANCE SERVICE SCHEDULE The 6900 KMC Subsoiler Leveler has been carefully designed and manufactured to provide years of dependable service. To maximize use and reduce downtime and repair costs, regular maintenance should be performed on the Subsoiler Leveler. Below is a guide for minimum recommended services and the time intervals for their completion. -
Page 44: Lubrication Points
LUBRICATION POINTS Several machine components require periodic lubrication: See the “Maintenance Service Sched- ule” portion of the manual for those periodic lubrication intervals. The following illustrations highlight those component areas that are fitted for lubrication. In all these areas it is important to use only a Moly EP Grease with a minimum service interval as described in the Maintenance Service Schedule. - Page 45 Toggle Trip Lubrication Points (2 Per Row) GREASE Swivel Coulter Turnbuckle Lubrication Points Lubrication Points (2 Per Row) (2 Per Row) GREASE GREASE...
-
Page 46: Wear Item Replacement
WEAR ITEM REPLACEMENT Shank Points Shank points should be checked for wear daily and more frequently in severe conditions. The photo on the left shows a point that is worn and ready to be replaced. If the point is left on the machine past this point the boot, or portion on the point that holds it onto the shank, will wear quickly. - Page 47 Replacing Coulter Disc Blades Front Swivel Coulter Blades 1. Remove 1/2 x 1-1/2 capscrews and the corresponding lockwasher and hexnut. 2. Remove worn disc from the bearing hub. (may need to lightly tap the disc with a hammer to remove) 3.
-
Page 48: Storage
STORAGE: The purchase of your Subsoiler Leveler is a substantial investment to your farming needs. For this reason, your Subsoiler Leveler should be cleaned and stored in a manner that will ensure the life and value of your investment for years to come. KMC recommends after each season of use to: ... - Page 49 The following is a list of serial numbers issued to our machines at the beginning of each year. To determine when a unit was made, find the range within which the particular serial num- ber falls. It would have been produced between January 1 to December 31 of that year. YEAR SERIAL NUMBERS 2013...
- Page 50 DEPENDABLE EQUIPMENT FOR PROGRESSIVE FARMING Visit us at www.kelleymfg.com KELLEY MANUFACTURING CO. 80 Vernon Drive / Zip 31794 Tel: 229-382-9393 P.O. Drawer 1467 / Zip 31793 Toll Free: 1-800-444-5449 Tifton, GA Fax: 229-382-5259 MADE IN AMERICA Email Address: info@kelleymfg.com...
