PHILLIPS 4505 ROTARY HARROW PART REFERENCE

17
15
8
6
1. Bearing Housing
2. Tooling Tension Rod
3. Tool Lever
4. Caster Bottom Plate
5. Wing Caster
6. Hitch
7. Safety Chain
8. Pig Tail Hose Holder
9. Hose Holder
10. Main Beam
11. Wrench
12. Front Wing Mount
13. Lock Lever
14. Extremity Light
15. Wing Hydraulic Cylinder
16. Wing Long Brace
SEPT 2008
45' Rotary Harrow
18
19
16
13
14
12
10
9
30
26
20
21
25
22
24
17. Wing Front Beam
18. Wing Tool Catcher
19. Wing Stiff Arm
20. Main Wheel
21. Main Wheel Back Plate
22. Rear Beam Brace
23. Front Wing Mount Brace
24. Rear Beam
25. Tail Hydraulic Cylinder
26. Tail Top Bridge
27. Long Tail Brace
28. Rear Tail
29. Tail Caster
30. Tail Tool Catcher
31. Tail Lights
2
29
31
27
30
11
2
5 4
3
28
1
