1.4 HARROW SAFETY LOCKS
The harrow is equipped with wing and tail
section lock. These locks are to be used at
all times when transporting the harrow. In
addition, the harrow comes equipped with a
safety chain which is also to be used in
transport at all times.
These photos show the location of the safety
devices on the harrow:
LH/RH Wing Lock
Safety Pin
45' Rotary Harrow
NOTE: Install the safety pins provided to
secure the wings and tail locking bar.
Failure to use the safety pins may cause
damage to the frame and void your
warranty.
1.5 SAFETY DECALS
The harrow comes with a complete set of
safety decals which are to be read and
thoroughly understood. Refer to Operators
Manual for locations and additional infor-
mation. In the event a decal is damaged
during setup it should be replaced immedi-
5
Tail Lock & Pin
Safety Chain
SEPT 2008
