- Page 1 33-SERIES 4-RWB & 6-ROW PEANUT COMBINE 3374 & 3376 TO BE USED FOR MACHINES FROM 2000 TO 2011 OPERATOR’S MANUAL THIS MANUAL TO ACCOMPANY MACHINE PART NO. 33-OM-04 Printing Date: JUNE 2010...
- Page 2 3-YEAR PEANUT COMBINE WARRANTY POLICY KELLEY MANUFACTURING COMPANY (KMC) warrants that Peanut Combines sold to the original purchaser shall be free of any defects in material and workman- ship if used under normal operating conditions. The warranty period begins on the date of purchase by the retail customer and ends thirty-six (36) months thereafter.
-
Page 3: 36 & 6 X 36 Pictures
4 X 36 KMC PEANUT COMBINE 6 X 36 KMC PEANUT COMBINE... -
Page 4: To The Purchaser
TO THE PURCHASER The KMC PEANUT COMBINE has been carefully designed and manufactured to give years of depend- able service. In order to operate it efficiently and maintain it properly, please read the instructions within this manual thoroughly. While reading the manual through, you will notice that it is divided into sections which clearly explain the assembly and operation of each component of this machine. -
Page 5: Table Of Contents
TABLE OF CONTENTS 4 X 36 & 6 X 36 PICTURES ......................1 TO THE PURCHASER ........................2 TO THE DEALER ..........................2 SAFETY PROCEDURES ........................ 2 ASSEMBLY INSTRUCTIONS ATTACH THE SIX ROW HEADER ....................4 MOUNT THE TANK TO THE COMBINE ..................4 MOUNT THE REAR HOOD ...................... -
Page 6: Assembly Instructions
ASSEMBLY INSTRUCTIONS There are several things which may need assembling before the peanut combine is ready for opera- tion. The assembly order will depend on how the machine has been disassembled for shipping. ATTACH THE SIX ROW HEADER Use extreme caution when attaching the head to the combine. -
Page 7: 6R Tire And Hub Installation
of hood and bolt holes in rear tube of combine. See ATTACH FOUR ROW TONGUE Figure 2. Connect Transport lights. 4RWB TIRE AND HUB INSTALLATION NOTE: TO MAKE 4RWB MACHINES LEVEL MOVE UP TO TOP HOLE AS SHOWN NOTE: BRACE ON BOTTOM Figure 4 Some combines may require the attachment of the pivot tongue. -
Page 8: Pre-Delivery Checkout
PRE-DELIVERY CHECKOUT 7. Connect hydraulic lines for header rotation. 1. Open all shields and check chains and belts for Operate slowly until all air has escaped from proper tension. the system. If using the flow control kit #33-081-229, be sure to locate it OUTSIDE of 2. -
Page 9: Principles Of Peanut Harvest
PRINCIPLES OF PEANUT HARVEST The KMC Peanut Combine is designed to be used for the removal of peanut pods from peanut vines which have been uprooted. It will then separate the peanuts from the vines, placing the pods in a storage tank on top of the machine, and return the vines to the ground. The combine must be pulled and powered by a farm tractor. -
Page 10: Fundamentals For Good Performance
FUNDAMENTALS FOR GOOD PERFORMANCE 1. The peanut vines must not be too green or good B. Use as much air as necessary to separate separation will be slow and difficult. peanuts from trash without blowing peanuts 2. Moisture content of the peanut should not be too out the rear of the combine. -
Page 11: Operation Instructions
OPERATION INSTRUCTIONS NOTE: KMC COMBINES SHOULD BE OPERATED AT A PTO SPEED RANGE OF 900 TO 1000 RPM FOR OPTIMUM PERFORMANCE AND FUEL EFFICIENCY. BEFORE HOOKING COMBINE TO THE SETTINGS FOR DRAWBAR YOKES TRACTOR 1/2” SPACER If 4-row combine is delivered with the tongue in the transport (center hitch) position, it must be repositioned to (left hitch) position for field use (see figure 6) to reposition tongue:... -
Page 12: Tractor Setup And Attaching To The Combine
4” DRAWBAR YOKE SETTING Figure 7 END VIEW HITCH BALL RECOMMENTED SHANK SIZE TORQUE 1 1/4” 415 FT LBS 1 3/8” 555 FT LBS 1 1/2” 760 FT LBS Use enough flatwashers under drawbar to allow cotter pin to lock castle nut when tightened to correct torque. -
Page 13: Special Attachment
Position tractor directly in front of double gear- box and in line with combine, not tongue. Remove transport u-bolt from tongue extension and store on upper tongue in provided location. Refer to Figure 7 & 8. Turn tongue extension to align with tractor drawbar and back tractor up until ball on drawbar is directly underneath coupler on tongue extension. -
Page 14: Pickup Auger Adjustment And Operation
PICKUP AUGER ADJUSTMENT NOTE: It is important that the auger be posi- tioned low enough to keep the trough swept clean AND OPERATION and prevent dirt and trash from building up. The purpose of the auger is to transfer vines to the center of the machine after they have been lifted CAUTION: MOVING AUGER FOR- by the pickup reel. -
Page 15: Picking Cylinders
PICKING CYLINDERS After the windrow has been picked up it moves into a series of cylinders which are equipped with spring tines that pull the peanuts off the vines. The cylinders are rotating at a high rate of speed, therefore it is important to keep a constant and adequate supply of material flowing into the combine to minimize damage and shelling of peanuts. - Page 16 Figure 15 UPPER STRIPPER ADJUSTMENT The aggressiveness of the picking cylinders can be Figure 17 LEFT SIDE LOWER STRIPPERS adjusted by increasing or decreasing the number of NOTE: Use a 15/16” wrench to make adjustments strippers engaged in the picking cylinders. When first easier.
-
Page 17: Axle Height Adjustment
sizes, one with a wide spacing 2 1/4” between rows of AXLE HEIGHT ADJUSTMENT fingers and one with a small 1 5/8” spacing. The 3374 and 3376 Model combines have an increased body to ground angle for improved The openings are controlled by two levers in the separation performance. - Page 18 4) Lift combine and set on blocks which will keep tires clear of ground. 5) Remove wheels from hubs and hub assemblies from axle end plates. On 6-row combines, remove lower shields from axle end plates. 6) Mount hub assemblies on axle end plates in upper holes so that two holes are exposed at bottom instead of top.
-
Page 19: Stemmer Saws
STEMMER SAWS In the event of duct plugging, 3 clean-out doors As the peanuts fall from the chaffer they fall onto are provided. Make sure these doors are installed a set of stemmer saws. These saws remove the stems properly; if not, they can create increased LSK’s. from the peanuts and dispose of the vine fragments. -
Page 20: Combine Transport
Periodic cleaning of the air release grid on the top When towing the combine on public roads be of the tank delivery duct may be necessary. See sure that the weight of the towing vehicle is equal to Figure 26B. A heavy buildup of vines and roots in or greater than the weight of the combine which is the grid can cause shelling of peanuts. -
Page 21: Trouble Shooting Other Parts Of The Combine
TROUBLE SHOOTING OTHER PARTS OF THE COMBINE PROBLEM POSSIBLE CAUSE AND SOLUTION 1. Vines rolling in front of pickup, not being picked 1. Small vines or high winds will not allow springs up by header. to penetrate vines. Install vine hold down attachment and for extreme conditions bend pickup spring up slightly 1”... - Page 22 PROBLEM POSSIBLE CAUSE AND SOLUTION 1. Too little air through separator. Turn control han- 6. Excessive foreign material in sample. dle to increase air. CW-6R, CCW-4R. 2. If material is small and dry, reduce aggressive- ness of stripper springs. 3. If material is small clods of soil, re-shaking of vines may be necessary.
-
Page 23: Push Rod Setting
PROBLEM POSSIBLE CAUSE AND SOLUTION 1. Check eccentric drive belts on BOTH sides of the 10. Excessive machine vibration. machine to be sure they are tight. CAUTION: Avoid over tightening of the belt on the right side as this could cause the shaft to bend due to an excessive overhung load. -
Page 24: Maintenance
MAINTENANCE There are certain things which need daily or regular attention to keep your combine in good operating condition. LUBRICATION is the most important of these. The following chart shows points that require lubrication and the intervals at which they require it. The cylinder bearings on the combine are prelubed and non-re- lubricatable. -
Page 25: Spring Maintenance
SPRING MAINTENANCE should be performed The drives for the combine should be inspected daily to insure peak performance of the combine. daily. The drives for all the cylinders and header are chain drives. These chains should be set where all the slack is taken out but not so that they are preloaded Pickup springs should be checked for broken or which can cause premature wear and failure. - Page 26 6-ROW Figure 33 NO. 6 & 7 CYLINDER DRIVE 4-ROW Figure 36 ECCENTRIC & JACKSHAFT DRIVE Figure 34 HEADER DRIVES The main drive, both fans, eccentric, and stemmer saws are all driven by V-belts. Proper installation and tension of the belts is necessary for optimum perform- ance.
-
Page 27: After Season Maintenance
Figure 38 STEMMER SAW DRIVE Figure 39 AIR LIFT FAN DRIVE AFTER SEASON MAINTENANCE 5. Grease all fittings, driveline, bearings, bushings, 1. Clean the combine thoroughly to remove all dirt and pivot joints. NOTE: MAKE SURE ALL and moisture holding materials. WATER IS PURGED FROM BEARINGS TO 2. -
Page 28: Specifications
SPECIFICATIONS HITCH: Stationary tractor drawbar types MACHINE WEIGHT: Four Row - 18,500 lbs Six Row - 19,000 lbs PICKUP REEL: Low profile, 5-bar, camless, 212” 155” 4-ROW, 165” 6-ROW MACHINE HEIGHT: wide on six row machines, 132” wide on four row machines. -
Page 29: Wiring Harness For Lights
WIRING HARNESS FOR LIGHTS REAR OF COMBINE RIGHT TAIL LIGHT LEFT TAIL LIGHT MOLDED CIRCUIT CONNECTOR 10 FT PIG TAIL 10 FT PIG TAIL FRONT COMBINE HARNESS AMBER LIGHT ASSEMBLY AMBER LIGHT ASSEMBLY 7-WAY PLUG ADAPTER TO REAR OF TRACTOR... -
Page 30: Tachometer Wiring
TACHOMETER WIRING DT8 TACHOMETER WIRING INSTRUCTIONS BACK SIDE OF TACHOMETER INPUT TERMINAL TERMINAL GROUND TERMINAL INPUT WIRE COMM WIRE (BLACK) (WHITE) SHIELD WIRE Connect the shield wire and white wire to the ground terminal. Connect the black wire to the input terminal. ... -
Page 31: Decals
TO AVOID DEATH OR SERIOUS INJURY FROM STAND CLEAR OF ALL ROTATING BELT DRIVES ENTANGLEMENT IN THE AUGER FEEDER SYSTEM. AND CHAIN DRIVEN PARTS. ENTANGLEMENT WITH ROTATING DRIVE PARTS DISENGAGE DRIVES AND SHUT OFF TRACTOR CAN CAUSE INJURY OR DEATH ENGINE BEFORE MANUALLY UNPLUGGING. - Page 32 33-050-146 TO AVOID SERIOUS INJURY OR DEATH: AVOID BANKS AND DITCHES. REDUCE SPEED ON TURNS, SLOPES, AND ROUGH TERRAIN. AVOID IMPLEMENT CONTACT WITH ELECTRICAL POWER LINES NEVER RAISE TANK UNDER POWERLINES OR ALLOW IMPLEMENT TO COME IN CONTACT WITH ELECTRICAL POWERLINES. ...
- Page 33 OPERATING RANGE 900 TO 1000 PTO R.P.M. KEEP PTO SHIELDS IN PLACE AT ALL TIMES 33-050-258 33-050-374 33-050-263 INSTALL COVER SO THAT AIRFLOW GOES IN THIS CLOSED DIRECTION 33-050-300 GREASE DAILY OPEN 33-050-133 33-050-233 33-050-414...
- Page 34 NOTES...
- Page 35 The following is a list of serial numbers issued to our machines at the beginning of each year. To determine when a unit was made, find the range within which the particular serial num- ber falls. It would have been produced between January 1 to December 31 of that year. YEAR SERIAL NUMBERS 1985...
- Page 36 DEPENDABLE EQUIPMENT FOR PROGRESSIVE FARMIMG Visit us at www.kelleymfg.com MADE IN AMERICA KELLEY MANUFACTURING CO. 80 Vernon Drive / Zip 31794 P.O. Drawer 1467 / Zip 31793 Tifton, GA Tel: 229-382-9393 Toll Free: 1-800-444-5449 Fax: 229-382-5259 Email Address: info@kelleymfg.com...
