OVERVIEW
1.0
This board interface is used for the connection between C82, C76, M16D, C35S, C62
and the YASKAWA SGDM
FEATURES
2.0
• MDR PLUG 50POS R/A GOLD connector for Driver Connection.
• RJ45 Connector for Axis.
• Encoder Output.
• Select Jumper for Hard Enable or Soft Enable.
• Select jumper for signal differentials.
• Terminals for external drive enable push button.
• Power Terminal 24V
User's Manual
*NEW
*NEW
