OVERVIEW

1.0
This card provides an easy way to connect your inputs and outputs from your port using
a LPH26pin Ribbon Cable or parallel port. Provides terminals for connections and
conditions signals for use in CNC applications.

FEATURES

2.0
• Terminal Block for all I/Os.
• Expansion port for Mother Board. Connect the C76 or ESS expansion board.
• Open collector Outputs pins optoisolated 2, 3, 4, 5, 6, 7, 8, 9, 1, 14, 16, 17.
• Input pins 10, 11, 12, 13, 15.
• Terminal Block input with close by ground or +5VDC connections, COM and
outputs with + 24VDC and ground
• Screw-On connections for all terminals. You only have to screw-on the wires to
make all your connections.
• Status LEDs for enable.
• Fully Optoisolated Inputs and Outputs.
• External Enable Pin
