2.6.1.4 Data Output—LOG SETUP Loop
After entering the LOG SETUP loop (both the LOG and SET icons are activated),
setup parameters are sent out when the SET button is pressed again. This informa-
tion can be sent out at any time in the LOG SETUP mode. HAL, temperature scale,
and the location number are sent out and terminated by a carriage return and line
feed. A total of 16 characters are sent out. Go to the appropriate location number in
the LOG loop and press the SET button to send out the Hi Alarm value for that loca-
tion. Activated Hi Alarm locations are uppercase (HAL), and unactivated Hi Alarm
locations are lowercase (hal). Only the HAL value at the present location is sent out.
For additional HAL values, go to the appropriate location and press SET again while
still in any of the two screens in the LOG SETUP mode. To get the LOG SETUP para-
meters for all 100 log locations, press the SET button for about 3 seconds.
Table 2-4 shows a sample output. The headings at the top of the table explain the con-
tents of each column (these are not part of the output).
Table 2-4: LOG SETUP Mode Output Example
or HAL
Notes:
1. For Location 1, HAL is not activated and is 1000°F.
2. For Location 2, HAL is activated and is 1000°F.
3. For Locations 3, 4, 5, 6, and 7, HAL is not activated and is 85°F.
4. For Location 8, HAL is activated and is 65°F.
Note: DOI does not apply to the LOG SETUP mode.
Raynger 3i Series Operator's Manual
S S S
p p p
a a a
hal HAL °C Location
c c c
Value or °F Number
e e e
hal 1000 F 001
HAL 1000 F 002
hal 0085 F 003
hal 0085 F 004
hal 0085 F 005
hal 0085 F 006
hal 0085 F 007
HAL 0065 F 008
Notes
Carriage Line
(see below)
Return Feed
<CR> <LF> 1
<CR> <LF> 2
<CR> <LF> 3
<CR> <LF> 3
<CR> <LF> 3
<CR> <LF> 3
<CR> <LF> 3
<CR> <LF> 4
2-27
