1.0

INTRODUCTION

1.1

DESCRIPTION

The Raynger 3i series of instruments are portable infrared temperature measure-
® ™
ment devices. Each model is rugged and easy to use for making fast, noncontact, non-
destructive temperature measurements. They can measure operating temperatures of
mechanical, electrical, or production equipment without removing the equipment
from service. They can also measure product temperatures during manufacturing or
storage without contaminating or marring the product. Table 1-1 lists the standard
Raynger 3i models.
MODEL
LTDL2 &
LTDL3
LTSC
LTCL2 &
LTCL3
LRSC
LRSCL2
LRL2 &
LRL3
P7DL2 &
P7DL3
G5SC
1MSC
(1100 to 5400 F)
1ML2 &
1ML3 (1100 to 5400 F)
2MSC
2ML2 &
2ML3
Raynger 3i Series Operator's Manual
Table 1-1: Raynger 3i Models
TEMPERATURE OPTICAL
RANGE RESOLUTION
-30 to 1200 C 75:1
(-20 to 2200 F)
-30 to 1200 C 75:1
(-20 to 2200 F)
-30 to 1200 C 75:1
(-20 to 2200 F)
-30 to 1200 C 120:1
(-20 to 2200 F)
-30 to 1200 C 105:1
(-20 to 2200 F)
-30 to 1200 C 120:1
(-20 to 2200 F)
10 to 800 C 25:1
(50 to 1450 F)
150 to 1800 C 50:1
(300 to 3275 F)
600 to 3000 C 180:1
600 to 3000 C 180:1
200 to 1800 C 90:1
(400 to 3275 F)
200 to 1800 C 90:1
(400 to 3275 F)
SPECTRAL
RANGE SIGHTING
8-14 dual laser
8-14 scope
8-14 crossed laser
8-14 scope
8-14 single laser with scope
8-14 single laser
7.9 dual laser
5.0 scope
1.0 scope
1.0 single laser
1.6 scope
1.6 single laser
1-1
