SpectraLink 8020/8030 Wireless Telephone: Administration Guide for SIP
108
MissedXmtCnt: The number of transmit packets dropped for not
•
receiving an ACK from the AP after all retries are exhausted.
RxRetryCount: The number of packets received with the retry bit
•
set.
TxRetryCount: The number of packets transmitted as retries.
•
Diagnostic display #2
........
Jitter 07500
LastRate 00054
GatewyType NoA2
TxPower(dBm) 00015
Jitter: Audio jitter in microseconds (us.) This is calculated in the
•
same way as the jitter reported in the audio statistics Syslog
message.
LastRate: The highest transmit date rate in megabits per second
•
(Mbps) at which the phone has successfully transmitted a packet
and received an ACK in the last second.
GatewyType: The gateway type (if any) that the phone is checked
•
in to. This will be one of the following:
2Mb: SVP server operating at 2 Mbps max speed.
−
11Mb: SVP server operating at 11 Mbps max speed.
−
− NoA2: No gateway in use (used with Wifi Qos.)
TxPower(dBm): Current transmit power in dBm. A table of dBm
•
values and the associated power in milliwatts is shown below:
dbM
7
10
13
15
16
17
20
mW
5
10
20
30
40
50
100
PN: 1725-36038-001_N.docx
