MINI-T-NX
Introduction

MINI-T-NX Display Version
The bottom line of the screen displays the version of the MINI-T-NX display (see

Illustration 5, MINI-T-NX Display Version Status Screen).

Illustration 5, MINI-T-NX Display Version Status Screen
Fri Apr 15 12:00:00PM
Display Ver: V1.0.0.1

MINI-T-NX Firmware Date
The bottom line of the screen displays the build date of the firmware currently loaded
on your MINI-T-NX (see Illustration 6, MINI-T-NX Firmware Date Status Screen).

Illustration 6, MINI-T-NX Firmware Date Status Screen

Fri Apr 15 12:00:00PM
FW Built: 03/30/07

IP Address
The bottom line of the screen displays the MINI-T-NX's IP address (see Illustration 7,
MINI-T-NX IP Address Status Screen).
Fri Apr 15 12:00:00PM
IP: 10:1:1:110

Site ID
The bottom line of the screen displays the MINI-T-NX site ID (see Illustration 8, MINI-
T-NX Site ID Status Screen).
Fri Apr 15 12:00:00PM
ID: MINI-T-NX
Page 28
WinLGX ver. 6.0.1.48

Illustration 7, MINI-T-NX IP Address Status Screen

Illustration 8, MINI-T-NX Site ID Status Screen
