Leightronix MINI-T-NX Manual page 103

FIELD
Icon Select the desired icon to represent your library item.
Input Choose the switcher input number to which the device is connected. If the
device is not connected to a switcher input, select "<None>." Assigning an
input to a device removes the input number from the input list.
NOTE:
Preferred You may assign a channel output to your device to automate device selection
Channel/Output for same-type library resources during scheduling. Whenever a library
resource of the same format is dragged onto this device's preferred playback
channel, this device will automatically appear in the library resource's
"Device" field.
"Switch (SW)" is automatically assigned.
Interface
Device The device numbers for switch resources are automatically assigned.
Select "Yes" to enable all of the resource's event records for printing. If "No"
Print
is selected, then you can enable printing as follows:
Select "Yes" to allow all of the resource's event records to be exported into
Export
comma delimited or Microsoft Excel
can enable the export function as follows:
LEIGHTRONIX, INC.
2018-06-08
1. Open the icon selection window by selecting the "Icon" field and
clicking the button that appears.
2. Select the desired icon.
3. Double click icon or click "OK." Click "Cancel" to abort selection.
The "Input" field appears after "Format" is selected.

Individual event records: select "Yes" in the "Print" field of each event
properties window that appears during scheduling of the resource.

All of the resource's event records: check the "Export/print all records"
option under the "Export/Print Templates" window.

Individual event records: select "Yes" in the "Export" field of each
event properties window that appears during scheduling of the
resource.

All of the resource's event records: check the "Export/print all records"
option under the "Export/Print Templates" window.
Software Installation & Configuration
DESCRIPTION
®
formats. If "No" is selected, then you
MINI-T-NX
Page 101
WinLGX ver. 6.0.1.48
