Leightronix MINI-T-NX Manual page 175

FIELD
Device Allows a same format device to be chosen. Its associated input will
appear in the "Input" field.
If the event is locked, the event "Time" can be modified. This is the
Time
scheduled "On-Air" time of the event.
Choose either the "PLAY" or "RECORD" command. It will nearly always
Command
be "PLAY."
(Event start)
Choose from the following commands: "STOP," "PAUSE," or "<None>."
Command
It will usually be "STOP."
(Event end)
NOTE:
Switchback Enter the input to be taken to the output at the end of the event.
input
Comment Use to change or enter a description with up to 31 characters.
Select "Yes" to enable the resource's event record for printing. If "No" is
Print
selected, then you can enable printing for all of the resource's event
records by checking the "Export/print all records" option under the
"Export/Print Templates" window.
Select "Yes" to to allow the resource's event record to be exported into
Export
comma delimited or Microsoft Excel
you can enable the export function for all of the resource's event records
by checking the "Export/print all records" option under the "Export/Print
Templates" window.
Maximum Each event properties window for a device or library resource item may be
configured to show different fields under a "minimum" and "maximum"
view
view (for instructions, see "Event Editor Tab" on page 81). To toggle
between these views, select and deselect the "Maximum view" checkbox.
LEIGHTRONIX, INC.
2018-06-08
DESCRIPTION
For DVD, check your interface manual and switches to
determine the actions performed by the "STOP" command. By
default, "STOP" stops the DVD at the current location.
Software Operation
®
formats. If "No" is selected, then
WinLGX ver. 6.0.1.48
MINI-T-NX
Page 173
