Leightronix MINI-T-NX Manual page 21

FEATURE
1 Internal MPEG Player
Internal MPEG Recorder
Option
1 PRO-BUS Port
2 Infrared (IR) Ports
LEIGHTRONIX, INC.
2018-06-08
SPECIFICATIONS
programming.
 Displays JPEG slides and MPEG video files
 Full D1 MPEG-2 resolution
 10Mb/s maximum video bit rate
 Configurable video/audio encode rates per recording
 Variable bit rate encoding
 Records for up to 6 hours
 Control up to 8 LEIGHTRONIX-supported VCRs and
some DVD players at once through individual PRO-BUS
device interfaces
 Provides four-function control (PLAY, STOP, REWIND,
and RECORD)
 Control up to 2 LEIGHTRONIX-supported VCRs and
some DVD players
 Provides four-function control (PLAY, STOP, REWIND,
and RECORD)
MINI-T-NX
Introduction
Page 19
WinLGX ver. 6.0.1.48
