Figure 53: Service Loop Diagram

Table 38: Service Loop Lengths

5.7 Top Cover Installation and Extension Test

This procedure provides instructions for installing the top cover and performing an enclosure extension test

for an Ultrastar Data102 .

Before you begin: Complete the instructions in

Table 39: Installation Requirements

Tool(s): Long T15 Torx Screwdriver

Cable Identifier

5.7 Top Cover Installation and Extension Test

Length to First Basket Clip

16 in / 406 mm

18 in / 457 mm

19 in / 483 mm

22 in / 559 mm

23 in / 584 mm

Cable Installation (page

55).

5. Installation
