Installation Guide
Step 3 : Test for binding in the extension of the arm by gently pulling the enclosure out of the rack,
ensuring the cables extend properly and that the system doesn't bind at all. If it does, examine
the point at which the binding occurred and adjust the seating of cables in the baskets, check
the connections to the rails, and examine the joints of the arm to ensure that they are all
functioning properly.
W hat to do next: T he data and power cables are now installed. Proceed to
Extension Test (page
5.6.1 SAS Cabling
The Ultrastar Data102 can use passive cables up to 3m in length, or active cables up to 10m, for SAS
connections to the host. All approved passive and active SAS cables are listed in the following tables.
Active Cabling
Active cables can be used for both direct (host-to-enclosure) and daisy-chain (enclosure-to-enclosure)
connections. When daisy-chaining multiple Ultrastar Data102 enclosures together, active cables must be
used between enclosures for improved signal integrity.
Important: Active Optical SAS cable support is limited to Broadcom 9300-, 9302-, and 9305-
series HBAs.
Note: MegaRAID adapters do not support the use of active SAS cables. If your configuration
requires the use of MegaRAID adapters, passive cables must be used.
Table 33: Approved Active Optical HD Mini-SAS to HD Mini-SAS Cables
Length
3m
4m
5m
6m
10m
Passive Cabling
Passive cables should only be used for direct (host-to-enclosure) connections.
Table 34: Approved Passive HD Mini-SAS to HD Mini-SAS Cables
Length
2m
4. Listed FOHHB23P00xxx cables are compatible, beginning with FW 2052-003.
68).
Manufacturer
Amphenol ICC (FCI)
Molex
Amphenol ICC (FCI)
Amphenol ICC (FCI)
Molex
Amphenol ICC (FCI)
Molex
Manufacturer
Amphenol ICC (FCI)
5. Installation
5.6 Cable Installation
Top Cover Installation and
Vendor Part Number
4
FOHHB23P00003
106415-2103
FOHHB23P00004
FOHHB23P00005
106415-2105
FOHHB23P00006
106415-2110
Vendor Part Number
601760006
62
