3
Applications
The MCTRL4K can work in mosaic and multi-card modes, meeting multiple user application needs.
Application 1: Mosaic Mode
Figure 3-1 Application of mosaic mode
Application 2: Multi-Card Mode
Figure 3-2 Application of multi-card mode
www.novastar.tech
MCTRL4K LED Display Controller User Manual
5
