7.4.1 Environment Configuration

Figure 7-5 Environment configuration diagram
Step 1 Connect the MCTRL4K to a PC (or a mobile device) via Ethernet cable or router.
Step 2 Obtain the IP address of the MCTRL4K from the top-right corner of home screen.
Step 3 Open the suggested web browser on your computer, enter "http//the above device IP address" in the address
bar, and then press Enter to jump to the Web Control page for the device.
Note
The MCTRL4K and PC (or mobile device) must be on the same LAN.

7.4.2 Operations

Figure 7-6 Web control page
Area A: Hardware connection statuses and loading capacities of the input, output and other connectors on the
MCTRL4K. For details, see chapter
Area B: Operations can be done in this area. For details, see chapter
Click the menu bar on the left of area B to select the option to be adjusted, and the corresponding operations
can be done on the right.
www.novastar.tech
MCTRL4K LED Display Controller User Manual
5 Home Screen.
6 Menu Operations.
