Control ETHERNET
USB IN-OUT
GENLOCK IN-
LOOP
Power AC 100 V~240 V-50/60 Hz
Note

When the input source is HDMI or DP, the 144 Hz forced resolution input from the front end device can
be parsed. In this situation, the loading capacity is reduced by half.

This product can only be placed horizontally. Do not mount vertically or upside-down.
www.novastar.tech
MCTRL4K LED Display Controller User Manual

OPT1 transmits the data of Ethernet ports 1 to 8.

OPT2 transmits the data of Ethernet ports 9 to 16.

OPT3 is a duplicate channel of OPT1.

OPT4 is a duplicate channel of OPT2.
Connect to the control computer.

IN: 1x USB 2.0 (Type-B)
Input port for cascading MCTRL4K units, or connecting to a PC for
debugging

OUT: 1x USB 2.0 (Type-A)
Output port for cascading MCTRL4K units
Up to 10 units can be cascaded.
Sync signal connector
Support for Bi-level, Tri-level, and Blackburst

IN: Genlock input connector

LOOP: Genlock loop output connector
