On the screen configuration page, click Save to save current configuration parameters to the
−
controller.
Note

The 3D and low latency functions cannot be enabled at the same time.

When the 3D function is enabled, any calibration operations cannot be performed.

When the advanced screen configuration is enabled, 3D function is not supported.

When the input source is DVI, DVI1 loads the images for left eye, and DVI2 loads the images for right
eye. When the 3D function is in use, the input mode cannot be switched to multi-card mode.

When the video source format is set to side-by-side or top-and-bottom, the frame rate of Ethernet output
will be doubled (for example, if the frame rate of input source is 60 Hz, the frame rate of Ethernet output
will be 120 Hz), and the loading capacity of Ethernet port will be reduced by half.

6.5.9 Genlock Setting

Set the Genlock phase offset to move the time of the sync source backward.
Figure 6-21 Genlock

6.5.10 Hardware Version

Check the hardware version of the controller. If a new version is released, you can connect the controller to a
PC to update the firmware programs in NovaLCT.
Communication Settings
Set the communication mode and network parameters of the MCTRL4K.
Figure 6-22 Communication settings
 Communication mode: Include USB preferred and Local Area Network (LAN) preferred.
