Basic System Description

Overview

The Simplex FACP has three general functions:
•
•
•
Note:
Facility
Specific
Control
Keys and
LEDs
It monitors fire alarm initiating points (smoke detectors, heat detectors, and pull stations).
It activates fire alarm notification appliances (horns, strobes, and audio evacuation messages)
when an initiating point activates.
It monitors and controls auxiliary building equipment (fan dampers, relays, security devices).
The term point is used extensively throughout this manual. It is a generic term used to
refer to an individual component of the system, such as a single smoke detector or a single
pull station. The FACP operator interface, shown in Figure 1-1, allows a system operator
to control and monitor the facility-specific components connected to the FACP.
LCD
Priority 2
Alarm LED
ACK Key
Fire Alarm
System
LED and
Supervisory
ACK Key
LED and ACK
Key
Figure 1-1. Flexible User Interface Controls
firealarmresources.com
Previous/
Softkeys
Next Keys
(total 6)
System
System
Trouble LED
Reset Key
and ACK Key
Alarm
Silence LED
and Key
1-2
Page Up/Page
Down Keys
Entry Keypad
Enter
Menu
Key
Key
AC
Power
LED
