Basic System Description,
LED/Key
Fire Alarm LED and Fire Alarm
ACK Key
Priority 2 Alarm LED and Priority 2
Ack Key
System Supervisory LED and
Supv ACK key
System Trouble LED and Trouble
ACK
Alarm Silenced LED/Alarm
Silence Key
System Reset Key
AC Power LED
Entry Keypad
Menu Key
Enter Key
Facility-Specific Control Keys
Page Up/Page Down Keys
Previous/Next
Flexible User Interface Softkeys
LCD
Note:
continued
The Fire Alarm LED flashes to indicate the presence of an unac-
knowledged alarm condition. Other components of the system,
such as the horns and strobes, also activate to indicate the pres-
ence of an alarm. The FIRE ALARM ACK key allows you to indi-
cate that you have observed the presence of an alarm.
The Priority 2 Alarm LED flashes to indicate the presence of an
abnormal condition with sprinkler systems.
The System Warning LEDs - Supervisory and Trouble - indicate
when abnormal, non-fire conditions occur to the fire alarm system's
wiring or devices. The system warning keys - SUPV ACK - allow an
operator to acknowledge the presence of the abnormal condition.
The System Trouble LED flashes to indicate the presence of an
unacknowledged trouble condition. Other components of the sys-
tem may be programmed to activate and indicate the presence of a
trouble. The TROUBLE ACK key allows you to indicate that you
have observed the presence of a trouble.
Pressing the ALARM SILENCE key provides a means of silencing
the building's audible notification appliances (horns). The LED indi-
cates when this key has been used.
Pressing this key directs the panel to reset all attached devices and
clear all acknowledged alarms, troubles, and supervisory condi-
tions.
Indicates the presence of AC power at the panel.
Used to call up points for monitoring and control.
Selects the main menu programmed in the Flexible User Interface
Processes the command displayed on the screen.
These are programmable keys. Typical functions include manual
evacuation and ground fault monitor.
Pressing these keys moves the cursor up or down by one screen.
Holding the key for 2 seconds shifts the cursor to the top or bottom
of the displayed information.
Pressing these keys moves the cursor up or down by one line.
Holding the key shifts the cursor up or down by one line at a 1/4
second increment.
These keys conform to the image on the LCD and can change
depending on the menu that has been selected.
Displays text describing abnormal conditions for devices attached
to the panel (e.g., a smoke detector in the main lobby is in alarm).
Also displays system prompts and messages.
The degree to which you are allowed to control the system depends on the passcode
assigned to you. See "Logging In and Out of the System" for details on this.
