Foundation Series 2606-9101 LCD Annunciator Installation Guide 2 Introduction The LCD Annunciator for the 2008-9101, 2050-9101, and 2250-9101 panels provide remote annunciation of the fire alarm control unit (FACU) status. The LCD display and LEDs indicate the visual status. The piezo sounder provides audible annunciation. You can enable or lock access to the Annunciator switch functions using the keyswitch, see Accessing the user interface.
Foundation Series 2606-9101 LCD Annunciator Installation Guide 3 Module overview See Figure 1 for the remote Annunciator front view and see Figure 2 for the back layout. Figure 1: Remote Annunciator front view Callout Description Callout Description LCD display RESET NAC silence Enter Key switch...
Page 8
Foundation Series 2606-9101 LCD Annunciator Installation Guide Figure 3: USB location, Annunciator rear view Callouts Description Screw locations USB location Table 2: Remote Annunciator main back components Components Description USB port (J1) Use for firmware upgrade. To access the USB port, remove the back plate. For more information contact technical support.
Foundation Series 2606-9101 LCD Annunciator Installation Guide Specifications • For use indoors in a dry location. • All connections are power-limited and supervised. Table 3: Measurements Height Length Depth 5 3/8 in. 6 7/8 in. 1 3/8 in. 13.65 cm 17.46 cm 3.49 cm Table 4: Power requirements and environmental limitations...
Foundation Series 2606-9101 LCD Annunciator Installation Guide 4 Mounting instructions To mount the Annunciator, complete the following steps: Unlock the Annunciator using the B-key provided and press location A to open the backplate as shown in Figure 4. Remove the back plate from housing. To remove the back plate, position the back plate at 90º to the housing as shown in Figure 4 and then tilt and detach the bottom interface of plate from housing first as shown in Figure 5.
Page 11
Foundation Series 2606-9101 LCD Annunciator Installation Guide Place the back plate on the mounting surface and mark the location of the four screw holes. Figure 6: Marking the location of the screw holes Callouts Description Press here Back plate Screw locations Using the four provided screws, mount the Annunciator back plate on the wall or mounting surface.
Foundation Series 2606-9101 LCD Annunciator Installation Guide Mounting the Annunciator using the surface mount box To mount the Annunciator using the surface mount box, complete the following steps Place the Annunciator on the surface mount box. Carefully align the mounting holes on the Annunciator wall plate with the surface mount box as shown in image Use the four #6-32 screws to mount the wall plate on the surface mount box.
Foundation Series 2606-9101 LCD Annunciator Installation Guide 5 Installing the LCD Annunciator To install the LCD Annunciator with the 2008 and 2250 FACU, complete the following step: Terminate the annunciators RS485 COMM and power line as shown in Figure 9 and Figure 10 . Figure 9: Terminating the COMM and power lines with addressable panel Figure 10: Terminating the COMM and power lines with conventional panel Note: At the last Annunciator, use a 100 Ohm termination resistor between A Rtn.
Foundation Series 2606-9101 LCD Annunciator Installation Guide Configuring the 2008 LCD Annunciator 5.1.1 Powering the Annunciator in conventional mode. Address switch SW9-1 must be in the OFF position. That is, conventional mode. Insert the key into the key switch and rotate it 90 degrees anticlockwise. For the first time that power is applied: Ensure that the communication cable is not connected between the FACU and the Annunciator.
Foundation Series 2606-9101 LCD Annunciator Installation Guide Configuring 2008 FACU for LCD ANN using Panel PC Tool There is no option to configure the annunciators in the Conventional Panel Programmer (CPP). You can use the personal computer tool to enable or disable annunciators that are connected to the 2008 FACU. To enable or disable annunciators that are connected to the FACU, complete the following step: •...
Enrolling starts and the Annunciators gets enrolled. After the Annunciator is successfully enrolled with the FACU and the panel is fault-free, the Annunciator's LCD displays information including time and date similar to the following example. SIMPLEX 2250 SYSTEM NORMAL 10:05:55 18 Apr 2023 5.3.3...
Foundation Series 2606-9101 LCD Annunciator Installation Guide 5.3.5.1 LCD backlight To configure the LCD backlight follow these steps. Use the Up or Down keys to select Set Backlight option from Menu. Press and release the ENTER key to enter the backlight menu.
Foundation Series 2606-9101 LCD Annunciator Installation Guide Configuring 2250 and 2050 FACUs for LCD Annunciator using PC tool To configure the 2250 FACU using the PC tool, complete the following steps: From the console list, select General Options. From the General Options menu, select the Annunciator tab. To configure the Annunciator select the Enable Annunciator checkbox.
Communication and power wiring must meet requirement: Model Simplex 2081-9044 overvoltage protectors (200 mA or less). • For maximum wire lengths with or without circuit protectors, see Table 6.
Page 20
Foundation Series 2606-9101 LCD Annunciator Installation Guide Table 6: Maximum distance supported for respective AWG for Annunciator quantity Maximum Maximum distance Maximum distance Maximum distance Maximum distance Maximum distance Annunciator QTY (ft) w/ 22 AWG (ft) w/ 20 AWG (ft) w/ 18 AWG (ft) w/ 16 AWG (ft) w/ 14 AWG 1244...
Foundation Series 2606-9101 LCD Annunciator Installation Guide 7 Checkout procedure When the installation is complete, verify that the remote Annunciator is working correctly: Execute a lamp test to verify that the LEDs and the LCDs are working, see Executing the lamp test.
Foundation Series 2606-9101 LCD Annunciator Installation Guide 8 Accessing the user interface Access to the user interface is disabled when the keyswitch is in a vertical position, see Figure 13. Figure 13: Using the keyswitch to enable access to the Annunciator switch Table 7: Key lock callouts and description Callouts Description...
Foundation Series 2606-9101 LCD Annunciator Installation Guide 9 Maintenance Create a log book of reference data. Use this log book to record all maintenance test results and details of any faults or problems that arise. Enter the details of the maintaining company. Perform the functional tests daily, weekly, quarterly, and annually. •...
Page 24
Additional listings may be applicable, contact your local Simplex® product supplier for the latest status. Listings and approvals under Simplex Time Recorder Co. Simplex, and the product names listed in this material are marks or registered marks. Unauthorized use is strictly prohibited.
