- Page 1 Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Catalog Numbers 1606-XLE240ERL, 1606-XLE240ERZ, 1606-XLE240CRZ, 1606-XLE240EDRZ Reference Manual Original Instructions...
- Page 2 Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Reference Manual Important User Information Read this document and the documents listed in the additional resources section about installation, configuration, and operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards.
-
Page 3: Table Of Contents
Table of Contents Product Overview ..........5 Specifications . - Page 4 Notes Rockwell Automation Publication 1606-RM110A-EN-P - July 2020...
-
Page 5: Product Overview
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Product Overview The Bulletin 1606-XLE line features cost optimized power supplies without compromising quality, reliability, and performance. The 1606-XLE240ERL and 1606-XLE240ERZ power supplies offer high efficiency, electronic inrush current limitation, active PFC, wide operational temperature range, and compact size. -
Page 6: Specifications
600 g (1.32 lb) — Catalog Numbers Catalog Number Description 1606-XLE240ERL 24V, 10 A 240 W Single-phase power supply with quick connect, spring-clamp terminals 1606-XLE240ERZ 24V, 10 A 240 W Single-phase power supply with hot swappable plug connectors 1606-XLE240ECRZ 24V, 10 A 240 W Single-phase power supply with conformal coated printed circuit boards... -
Page 7: Ac Input
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input AC Input The device is suitable to be supplied from TN-, TT-, and IT mains networks with AC voltage. For suitable DC supply voltages See DC Input on page Attribute Value Notes... -
Page 8: Dc Input
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input DC Input The device is suitable to be supplied from a DC input voltage. Use a battery or a similar DC source. A supply from the intermediate DC-bus of a frequency converter is not recommended and can cause a malfunction or damage the unit. -
Page 9: Input Inrush Current
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Input Inrush Current An active inrush limitation circuit limits the input inrush current after turn-on of the input voltage. The charging current into EMI suppression capacitors is disregarded in the first microseconds after switch-on. -
Page 10: Output
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Output The output provides a SELV/PELV/ES1 rated voltage, which is galvanically isolated from the input voltage. The output of the devices includes a decoupling MOSFET for building 1+1 or n+1 redundant power supply systems. The device is designed to supply any kind of loads, including capacitive and inductive loads. -
Page 11: Hold-Up Time
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input PLUS Figure 8 - Output Voltage Versus Output Current, Typ Figure 9 - Short-circuit on Output, Hiccup Mode, Typ Output Voltage Output Current Normal Normal Short -circuit operation operation A: continuous current B: intermitted current Output... -
Page 12: Dc Ok Relay Contact
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input DC OK Relay Contact This feature monitors the output voltage of the power supply in front of the decoupling device. Contact closes As soon as the output voltage reaches Typ 22V DC. As soon as the output voltage dips below 22V DC. -
Page 13: Efficiency And Power Losses
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Efficiency and Power Losses AC 100V AC 120V AC 230V 92.2% 93.0% 94.7% At 10 A Efficiency 91.9% 92.8% 94.6% At 12 A (Power Boost) Average 25% at 2.5 A, 25% at 5 A, 91.8% 92.4% 93.9%... -
Page 14: Lifetime Expectancy
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Lifetime Expectancy The Lifetime expectancy that is shown in the table indicates the minimum operating hours (service life) and is determined by the lifetime expectancy of the built-in electrolytic capacitors. Lifetime expectancy is specified in operational hours and is calculated according to the capacitor specifications. -
Page 15: Functional Diagram
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Functional Diagram Figure 18 - Functional diagram 1606-XLE240ERL Input Fuse Input Filter Output Power Decoupling Filter Converter Input Converter Active Inrush Limiter DC-ok Output Voltage DC-ok Temper- Output Monitor... -
Page 16: Terminals And Wiring
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Terminals and Wiring The terminals are IP20 fingersafe constructed and suitable for field- and factory wiring. 1606-XLE240ERL Input Output DC OK-Signal Type Quick-connect spring-clamp termination Push-in termination Solid wire max 6 mm 1.5 mm... -
Page 17: Replacing Units While The System Is Running
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Replacing Units While the This feature is available only for the 1606-XLE240ERZ, -XLE240CRZ, and -XLE240EDRZ units, which are equipped with hot-swappable plug connectors. System is Running Figure 20 - Replacing the power supply or redundancy module while the system is running Load Output 24V 10A Output 24V 10A... -
Page 18: Front Side And User Elements
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Front Side and User Elements Figure 22 - 1606-XLE240ERZ, Figure 21 - 1606-XLE240ERL User Elements -XLE240CRZ, -XLE240EDRZ Input Terminals N, L N, L Line Input PE (Protective Earth) Input... -
Page 19: Electromagnetic
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Electromagnetic The electromagnetic compatibility (EMC) behavior of the device is designed for applications in industrial environment and in residential, commercial, and Compatibility light industry environments. EMC Immunity According to the generic standards EN 61000-6-1 and EN 61000-6-2. Contact discharge 8 kV Criterion A... -
Page 20: Environment
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Environment Attribute Value Notes Operational temperature is the same as the ambient or Operational temperature -25…+70 °C (-13…+158 °F) surrounding temperature and is defined as the air temperature 2 cm below the unit. Storage temperature -40…+85 °C (-40…+185 °F) For storage and transportation... -
Page 21: Safety And Protection Features
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Safety and Protection Features 500 MΩ At delivered condition between input and output, measured with 500V DC 500 MΩ At delivered condition between input and PE, measured with 500V DC Isolation resistance 500 MΩ... -
Page 22: Dielectric Strength
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input ielectric trength The output voltage is floating and has no ohmic connection to the ground. Type and routine tests are conducted by the manufacturer. Field tests may be conducted in the field using the appropriate test equipment which applies the voltage with a slow ramp (2 s up and 2 s down). -
Page 23: Certifications And Standards Compliance
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Certifications and Standards Compliance The CE mark indicates conformance with the EMC directive (available), EC Declaration of Conformity Low-voltage directive (available) and the ATEX directive (planned) IEC 60950-1 CB Scheme for I.T.E. 2nd Edition Information Technology Equipment IEC 62368-1... -
Page 24: Approximate Dimensions
(Example: another power supply). Penetration protection Small parts like screw with a diameter larger than 4 mm (1) Without plug connectors. Figure 26 - Front View 1606-XLE240ERL Figure 27 - Side View 1606-XLE240ERL All dimensions in mm All dimensions in mm... -
Page 25: Applications Notes
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Applications Notes Peak Current Capability The unit can deliver peak currents (up to several milliseconds) which are higher than the specified short term currents. This helps to start current demanding loads. Solenoids, contactors and pneumatic modules often have a steady state coil and a pick-up coil. -
Page 26: Adjusting The Output Voltage
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Adjusting the Output Voltage A voltage adjustment potentiometer can be found behind the flap on the front of the unit. However, it is not recommended to change the output voltage since load sharing between power supplies connected in parallel can only be achieved by a precise setting of the output voltages. -
Page 27: Charging Of Batteries
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Charging of Batteries This redundancy power supply is ideal for charging batteries due to the decoupling circuit built in to the output stage which does not require a fuse or diode between the power supply and the battery. -
Page 28: Output Circuit Breakers
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Output Circuit Breakers Standard miniature circuit breakers (MCBs or UL 1077 circuit breakers) are commonly used for AC-supply systems and may also be used on 24V branches. MCB’s are designed to protect wires and circuits. If the ampere value and the characteristics of the MCB are adapted to the wire size that is used, the wiring is considered as thermally safe regardless of whether the MCB opens or not. -
Page 29: Series Operation
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Series Operation Power supplies of the same type can be connected in series for higher output voltages. It is possible to connect as many units in series as needed, providing the sum of the output voltage does not exceed 150V DC. -
Page 30: Parallel Use To Increase Output Power
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Parallel Use to Increase Output Power Power supplies can be paralleled to increase the output power. For redundancy applications one extra power supply is always needed for sufficient output current in case one unit fails. -
Page 31: Parallel Use For Redundancy
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Parallel Use For Redundancy Power supplies can be paralleled for redundancy to gain higher system availability. The unit is already equipped with a MOSFET as decoupling device on the output to avoid, that a faulty unit becomes a load for the other power supplies and the output voltage cannot be maintained any more. -
Page 32: Operation On Two Phases
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Operation on Two Phases The power supply can also be used on two-phases of a three-phase-system. Such a phase-to-phase connection is allowed as long as the supplying voltage is below 240V+10%. -
Page 33: Mounting Orientations
Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Mounting Orientations Mounting orientations other than all terminals on the bottom require a reduction in continuous output power or a limitation in the maximum allowed ambient temperature. The amount of reduction influences the lifetime expectancy of the power supply. - Page 34 Redundancy Power Supply - 24V, 10 A, 240 W, Single-phase Input Notes: Rockwell Automation Publication 1606-RM110A-EN-P - July 2020...
-
Page 35: Additional Resources
Power Supply Technical Data, publication 1606-TD002. Provides product selection, specifications, and dimensions information. Industrial Components Preventive Maintenance, Enclosures, and Contact Provides a quick reference tool for Allen-Bradley industrial automation controls and Ratings Specifications, publication IC-TD002 assemblies. Designed to harmonize with NEMA Standards Publication No. ICS 1.1-1987 and provides... - Page 36 At the end of life, this equipment should be collected separately from any unsorted municipal waste. Rockwell Automation maintains current product environmental information on its website at rok.auto/pec. Allen-Bradley, expanding human possibility, FactoryTalk, and Rockwell Automation are trademarks of Rockwell Automation, Inc. EtherNet/IP is a trademark of ODVA, Inc.
