Reference Manual
Bulletin 1606 Switched Mode Power Supplies
Catalog Number: 1606-XLS960E-3
Index
1.
Intended Use .......................................................3
2.
Installation Requirements...................................3
3.
AC-Input...............................................................4
4.
Input Inrush Current ...........................................5
5.
DC-Input...............................................................5
6.
Output .................................................................6
7.
Hold-up Time.......................................................8
8.
DC-OK Relay Contact ..........................................9
9.
Shut-down Input .................................................9
11. Internal Data Logging.......................................10
12. Efficiency and Power Losses..............................11
13. Reliability ...........................................................12
14. Functional Diagram...........................................12
15. Terminals and Wiring........................................13
16. Front Side and User Elements...........................14
17. EMC....................................................................15
18. Environment ......................................................16
19. Protection Features ...........................................17
20. Safety Features ..................................................17
21. Dielectric Strength ............................................18
Terminology and Abbreviations
• PE and
symbol-PE is the abbreviation for Protective Earth and has the same meaning as the symbol
• Earth, Ground-This document uses the term "earth" which is the same as the U.S. term "ground".
• T.b.d.-To be defined, value or description will follow later.
• AC 400V-A figure displayed with the AC or DC before the value represents a nominal voltage with standard tolerances (usually ±15%)
included. E.g.: DC 12V describes a 12V battery whether it is full (13.7V) or flat (10V)
• 400Vac-A figure with the unit (Vac) at the end is a momentary figure without any additional tolerances included.
• 50Hz vs. 60Hz-As long as not otherwise stated, AC 230V parameters are valid at 50Hz mains frequency.
• may-A key word indicating flexibility of choice with no implied preference.
• shall-A key word indicating a mandatory requirement.
• should-A key word indicating flexibility of choice with a strongly preferred implementation.
P
a
g
e
22. Certifications .................................................. 18
23. Physical Dimensions and Weight .................... 19
24. Accessories ....................................................... 20
25. Application Notes ............................................. 21
25.1. Repetitive Pulse Loading..........................21
25.2. Peak Current Capability ...........................22
25.3. External Input Protection.........................22
25.6. Output Circuit Breakers............................24
25.8. Parallel Use for Redundancy ....................25
25.9. Series Operation .......................................26
25.11. Back-feeding Loads ..................................26
25.13. Mounting Orientations ............................27
P
a
g
e
...............................24
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1606-XLS960E-3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Allen-Bradley 1606-XLS960E-3

Summary of Contents for Allen-Bradley 1606-XLS960E-3

  • Page 1: Table Of Contents

    Reference Manual Bulletin 1606 Switched Mode Power Supplies Catalog Number: 1606-XLS960E-3 Index 22. Certifications ..........18 Intended Use ............3 Installation Requirements........3 23. Physical Dimensions and Weight ....19 AC-Input...............4 24. Accessories ............20 Input Inrush Current ...........5 24.1. Wall mounting bracket - 1606-XLC..20 DC-Input...............5...
  • Page 2 Remote Control of Output Voltage DC-OK Relay Contact Shut-down Input 3 Year Warranty Description Specification Quick Reference The most outstanding features of the 1606-XLS960E-3 Output voltage DC 24V nominal DIN rail power supply are its extremely high Adjustment range 24 - 28V...

  • Page 3: Intended Use

    Bulletin 1606 Switched Mode Power Supplies 1. Intended Use • This device is designed for installation in an enclosure and is intended for the general professional use such as in industrial control, office, communication, and instrumentation equipment. • Do not use this power supply in equipment where malfunction may cause severe personal injury or threaten human life. •...

  • Page 4: Ac-Input

    Bulletin 1606 Switched Mode Power Supplies 3. AC-Input AC input nom. 3AC 380-480V suitable for TN, TT and IT mains networks, grounding of one phase is allowed except in UL 508 applications AC input range min. 3x 323-576Vac continuous operation Allowed voltage L to earth max.

  • Page 5: Input Inrush Current

    Bulletin 1606 Switched Mode Power Supplies 4. Input Inrush Current The power supply is equipped with an active inrush current limitation circuit, which limits the input inrush current after turn-on to a negligible low value. The input current is usually smaller than the steady state input current. 3AC 400V 3AC 480V Inrush current...

  • Page 6: Output

    Bulletin 1606 Switched Mode Power Supplies 6. Output Output voltage nom. Adjustment range min. 24-28V guaranteed max. ***) at clockwise end position of potentiometer Factory setting typ. 24.1V ±0.2%, at full load, cold unit, in “single use” mode typ. 24.1V ±0.2%, at full load, cold unit, in “parallel use”...
  • Page 7 Bulletin 1606 Switched Mode Power Supplies Fig. 6-1 Output voltage vs. output current in Fig. 6-2 Output voltage vs. output current in “single use” mode, typ. “parallel use” mode, typ. Output Voltage Output Voltage (Parallel Use, typ.) Adjustment Range Adjustment Range Factory setting Continuously...

  • Page 8: Hold-Up Time

    Bulletin 1606 Switched Mode Power Supplies 7. Hold-up Time 3AC 400V 3AC 480V Hold-up Time typ. 50ms 50ms at 24V, 20A, see Fig. 7-1 min. 40ms 40ms at 24V, 20A, see Fig. 7-1 typ. 25ms 25ms at 24V, 40A, see Fig. 7-1 min.

  • Page 9: Dc-Ok Relay Contact

    Bulletin 1606 Switched Mode Power Supplies 8. DC OK Relay Contact This feature monitors the output voltage, which is produced by the power supply itself. It is independent of a back-fed voltage from a unit connected in parallel to the power supply output. Contact closes As soon as the output voltage reaches 90% of the adjusted output voltage.

  • Page 10: Remote Control Of Output Voltage

    Bulletin 1606 Switched Mode Power Supplies 10. Remote Control of Output Voltage The shut-down input can also be used to remotely adjust the output voltage between typically 14Vdc and 28Vdc. All other functions of shut-down input remain the same. The control voltage is referenced to the main ground (negative output voltage). Fig.

  • Page 11: Efficiency And Power Losses

    Bulletin 1606 Switched Mode Power Supplies 12. Efficiency and Power Losses Efficiencies for 3-Phase operation: 3AC 400V 3AC 480V Efficiency typ. 95.3% 95.2% at 24V, 40A Average efficiency typ. 94.7% 94.6% 25% at 10A, 25% at 20A, 25% at 30A. 25% at 40A Power losses typ.

  • Page 12: Reliability

    Bulletin 1606 Switched Mode Power Supplies 13. Reliability 3AC 400V 3AC 480V Calculated lifetime expectancy 314 000h 294 000h at 24V, 20A and 25°C 111 000h 104 000h at 24V, 20A and 40°C 179 000h 174 000h at 24V, 40A and 25°C 63 000h 62 000h at 24V, 40A and 40°C...

  • Page 13: Terminals And Wiring

    Bulletin 1606 Switched Mode Power Supplies 15. Terminals and Wiring The terminals are IP20, finger safe, constructed and suitable for field and factory wiring. Input Output DC-OK, Shut-down Type screw termination screw termination spring-clamp termination Solid wire 0.5-6mm 0.5-16mm 0.15-1.5mm Stranded wire 0.5-4mm 0.5-10mm...

  • Page 14: Front Side And User Elements

    Bulletin 1606 Switched Mode Power Supplies 16. Front Side and User Elements Fig. 16-1 Front side A Input Terminals (Screw terminals) L1, L2, L3 Line input ...PE (Protective Earth) input B Output Terminals (Screw terminals, two pins per pole) Positive output –...

  • Page 15: Emc

    Bulletin 1606 Switched Mode Power Supplies 17. EMC The power supply is suitable for applications in industrial environment as well as in residential, commercial and light industry environment without any restrictions. A detailed EMC report is available on request. EMC Immunity According generic standards: EN 61000-6-1 and EN 61000-6-2 Electrostatic discharge EN 61000-4-2...

  • Page 16: Environment

    Bulletin 1606 Switched Mode Power Supplies Switching Frequencies The power supply has three converters with three different switching frequencies included. One is nearly constant. The others are variable. Switching frequency 1 105kHz Resonant converter, nearly constant Switching frequency 2 1kHz to 150kHz Boost converter, load dependent Switching frequency 3 40kHz to 300kHz...

  • Page 17: Protection Features

    Bulletin 1606 Switched Mode Power Supplies 19. Protection Features Output protection Electronically protected against overload, no-load and short-circuits Output over-voltage protection typ. 30Vdc In case of an internal power supply defect, a redundant max. 32Vdc circuit limits the maximum output voltage. The output shuts down and automatically attempts to restart.

  • Page 18: Dielectric Strength

    Bulletin 1606 Switched Mode Power Supplies 21. Dielectric Strength The output voltage is floating and has no ohmic connection to the ground. Type and factory tests are conducted by the manufacturer. Field tests may be conducted in the field using the appropriate test equipment which applies the voltage with a slow ramp (2s up and 2s down).

  • Page 19: Physical Dimensions And Weight

    Bulletin 1606 Switched Mode Power Supplies 23. Physical Dimensions and Weight Weight 1500g / 3.3lb DIN rail Use 35mm DIN rails according to EN 60715 or EN 50022 with a height of 7.5 or 15mm. The DIN rail height must be added to the unit depth (127mm) to calculate the total required installation depth.

  • Page 20: Accessories

    Output The 1606-XLSRED80 is the preferred redundancy module for the 1606-XLSRED80 Parallel Use Parallel Use Redundancy 1606-XLS960E-3 power supply. It is equipped with two input Module Single Use Single Use channels that are individually decoupled by using mosfet Input Input...

  • Page 21: Application Notes

    Bulletin 1606 Switched Mode Power Supplies 25. Application Notes 25.1. Repetitive Pulse Loading Typically, a load current is not constant and varies over time. This power supply is designed to support loads with a higher short-term power demand (=BonusPower). The short-term duration is hardware controlled by an output power manager and is available on a repeated basis.

  • Page 22: Peak Current Capability

    Bulletin 1606 Switched Mode Power Supplies 25.2. Peak Current Capability The power supply can deliver peak currents (up to several milliseconds) which are higher than the specified short term currents. This helps to start current demanding loads. Solenoids, contactors and pneumatic modules often have a steady state coil and a pick-up coil.

  • Page 23: Using Only 2 Legs Of A 3-Phase System

    Bulletin 1606 Switched Mode Power Supplies 25.4. Using Only Two Legs of a 3-Phase System No external protection devices are required to protect against a phase-loss Power Supply failure. This power supply can also be permanently operated on two legs of a 3- phase system.

  • Page 24: Charging Batteries

    Bulletin 1606 Switched Mode Power Supplies 25.5. Charging Batteries The power supply can be used to charge lead-acid or maintenance free batteries. (Two 12V batteries in series.) Instructions for charging batteries: Set output voltage (measured at no load and at the battery end of the cable) very precisely to the end-of-charge voltage.

  • Page 25: Parallel Use To Increase Output Power

    Bulletin 1606 Switched Mode Power Supplies 25.7. Parallel Use to Increase Output Power Power supplies from the 16060-XLS series can be paralleled to increase Unit A the output power. The output voltage shall be adjusted to the same value (±100mV) in “Single use” mode with the same load conditions on all units, or the units can be left with the factory settings.

  • Page 26: Series Operation

    Bulletin 1606 Switched Mode Power Supplies 25.9. Series Operation Unit A Power supplies of the same type can be connected in series for higher output voltages. It is possible to connect as many units in series as needed, providing the sum of the output voltage does not exceed 150Vdc. Voltages with a potential above 60Vdc are no longer SELV and can be dangerous.

  • Page 27: Mounting Orientations

    Bulletin 1606 Switched Mode Power Supplies 25.13. Mounting Orientations Mounting orientations other than all terminals on the bottom require a reduction in continuous output power or a limitation in the maximum allowed ambient temperature. The amount of reduction influences the lifetime expectancy of the power supply.
  • Page 28 Rockwell Automation Support Rockwell Automation provides technical information on the Web to assist you in using its products. At http://www.rockwellautomation.com/support, you can find technical manuals, technical and application notes, sample code and links to software service packs, and a MySupport feature that you can customize to make the best use of these tools.
