Record
Choose whether to record continuously for your cameras or by event type (Human, Face or
Motion). Select which camera you want to edit, click Continuous or Events and then use your
mouse to click and drag over the day and times you want to apply that new record setting.
1. Camera: Choose which camera to edit.
2. Continuous: Enable continuous recording in the time diagram.
3. Event: Enable motion recording in the time diagram.
4. None: Disable the selection of both continuous and motion recordings.
5. Copy To: Allows you to copy the configuration for one camera to another.
6. Time Diagram: Shows a diagram (hours of the day x day of the week). Use this diagram to
apply motion recordings and/or continuous recordings during specified periods.
Export Recordings
Search and playback all recorded video from this menu. Choose your desired date and times
from the options below, then click Play to view recorded video. Right-click to exit back to the
menu screen.
NOTE: See Backing Up / Exporting Videos section above for information on formatting
36
1
5
your USB Device.
2
3
4
6
WNIP2 Series User's Manual
- Quick Links:
- Initial Setup
- Troubleshooting
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the WNIP2 Series and is the answer not in the manual?
Questions and answers
I have model WNIP-2LTA-BS-U stand alone camera. I previously had this device in use for my garage. we had to change routers and now have different password. I **** not able to get the camera connected
To connect the Night Owl WNIP-2LTA-BS-U camera to a new router with a different password, you need to bypass its default pairing with the NightOwl NVR. Follow these steps:
1. Configure a wireless access point (AP) with the same SSID and password (PSK) that the camera was originally paired with.
2. Set up a new VLAN on your router or firewall with the same IP range that was used by the original NVR.
3. Assign this VLAN to the AP to simulate the original NVR environment.
4. Add routing rules in your firewall so that your LAN can access the camera network.
5. The cameras will connect to the new AP using the same credentials and be accessible as standalone ONVIF-compatible cameras.
This setup removes the cameras from NightOwl's control and allows use with third-party NVRs like BlueIris or VLC.
This answer is automatically generated
I need help with getting the phone on the App
To connect your Night Owl WNIP2 Series camera to the app:
1. Open the Night Owl Protect app.
2. Tap "Add New" and select "Standalone Camera."
3. Tap "OK" to allow the app to scan the camera’s QR code.
4. Tap "Use Your Network to Discover Your Device," then tap "OK."
5. Tap "Use Your Network to Discover Your Device" again.
6. Tap on the detected device and confirm by tapping "Yes."
7. Go to your device settings, tap "Wi-Fi," and connect to the network starting with "noip."
8. Once connected (checkmark appears), return to the app.
9. The app will search for the camera automatically.
10. Select your Wi-Fi network, enter the password, and tap "Continue."
11. When the screen says "Device has been added" and the camera says "Woohoo," setup is complete.
12. Name the camera and tap "Live View" to see the live stream.
