General Menu
The general menu will allow you to access display and network settings for your Wi-Fi NVR
system.
Network
Find network values and optimize connectivity based on your Internet connection. In most
cases the values should populate automatically once your Wi-Fi NVR is connected to the
Internet. The values in this section should only be adjusted if you are an advanced user and
have extensive experience in device networking.
NOTE: Do not adjust the Advanced settings unless you are knowledgeable and
Function
DHCP
IP ADDRESS
SUBNET MASK
GATEWAY
MAC ADDRESS
PREFERRED DNS
WEB PORT
NETWORK
BANDWIDTH
NETWORK STATUS
Support.NightOwlSP.com
understand the changes being made to the Wi-Fi NVR.
Description
Network configuration mode that gathers the network values automatically
from DHCP server. If unchecked this value can be set manually.
Network address of the connected Wi-Fi NVR.
The range of IP addresses that can be found in the network. This should
always be set to the default address 255.255.255.000.
The connection between two networks. This should always be the IP address
of the connected router.
The unique identifier assigned to network interfaces for communications at
the data link layer.
Domain Name System server address.
Allows access to your Wi-Fi NVR with your computer through your LAN or the
Internet. The default value is 80.
Defines channel capacity, or the maximum throughput of the network
interface.
Shows status of the network connectivity.
27
