Review Previously Detected Events using the Playback Feature
Use the Playback feature to replay recorded events. To access the Playback feature, click
the Playback button from the Right-Click Menu on the bottom of the Live View screen. The
following screen will appear.
A
H
Callout
Function
A
Video Image: Shows an image of the cameras that have video for the search parameters
entered.
B
Calendar: Allows you to search by date.
C
Camera: Allows you to search certain cameras.
Motion/Continuous: Allows you to search for Doorbell ring, Face, Human, Motion or
D
Continuous recordings.
E
Search: Activates the search based on the criteria established above and shows the recordings
found on the table below.
F
File Playback: Allows you to focus in on the video recording selected in the table above and
control the recording.
G
Backup: Allows you to switch the timeline between a day or hour scale.
H
Day/Hour: Allows you to switch the timeline between a day or hour scale.
Timeline: Shows the presence of a video recording and shows the progress of the video.
I
J
Controls: Allows you to control (rewind, fast-forward, pause, play, etc.) a video.
20
I
J
G
WNIP2 Series User's Manual
B
C
D
E
F
- Quick Links:
- Initial Setup
- Troubleshooting
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the WNIP2 Series and is the answer not in the manual?
Questions and answers
I have model WNIP-2LTA-BS-U stand alone camera. I previously had this device in use for my garage. we had to change routers and now have different password. I **** not able to get the camera connected
To connect the Night Owl WNIP-2LTA-BS-U camera to a new router with a different password, you need to bypass its default pairing with the NightOwl NVR. Follow these steps:
1. Configure a wireless access point (AP) with the same SSID and password (PSK) that the camera was originally paired with.
2. Set up a new VLAN on your router or firewall with the same IP range that was used by the original NVR.
3. Assign this VLAN to the AP to simulate the original NVR environment.
4. Add routing rules in your firewall so that your LAN can access the camera network.
5. The cameras will connect to the new AP using the same credentials and be accessible as standalone ONVIF-compatible cameras.
This setup removes the cameras from NightOwl's control and allows use with third-party NVRs like BlueIris or VLC.
This answer is automatically generated
I need help with getting the phone on the App
To connect your Night Owl WNIP2 Series camera to the app:
1. Open the Night Owl Protect app.
2. Tap "Add New" and select "Standalone Camera."
3. Tap "OK" to allow the app to scan the camera’s QR code.
4. Tap "Use Your Network to Discover Your Device," then tap "OK."
5. Tap "Use Your Network to Discover Your Device" again.
6. Tap on the detected device and confirm by tapping "Yes."
7. Go to your device settings, tap "Wi-Fi," and connect to the network starting with "noip."
8. Once connected (checkmark appears), return to the app.
9. The app will search for the camera automatically.
10. Select your Wi-Fi network, enter the password, and tap "Continue."
11. When the screen says "Device has been added" and the camera says "Woohoo," setup is complete.
12. Name the camera and tap "Live View" to see the live stream.
This answer is automatically generated
