Table 17. Mainboard connector legend
Letter
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V

USB 2.0 connector

One USB 2.0 Type-A connector is provided on the mainboard for internal USB dongle, with another on the backplane board.

Mini PCIe connector

The internal Mini PCIe connector (Rev. 1.2) supports full-size Mini PCIe cards.

SATA connector

The SATA connector supports transfer up to 6.0 Gb/s (600 MB/s).
22 System Layout
Description
Smart fan (future expansion)
SATA
USB 2.0 dongle
SATA
DDR4 SO-DIMM
PCIe x16 slot for PEG and SATA
M.2
Wafer for reserved power of extensions
USIM for M.2
USIM for Mini PCIe
Mini PCIe
Wafer for I2C sensor
Wafer for speaker
Wafer for COM x2 (optional), 8-ch DI, 8-ch DO, mic in and line out
Wafer for COM x4
Wafer for I2C sensor
Internal power button
PCIe x16 slot for PCIe and BP power
RTC battery
Board-to-Board for AFM board
PWR for AFM MXM carrier board (12 V)
Clear CMOS Jumper
