Table 50. 5G features (continued)
Feature
Category
Output power
4G
Bands
Band combinations
4x4 MIMO
RX diversity
Category
Output power
3G
Bands
RX diversity
Category
Output power

Antenna interface specification

Measurement conditions: ambient temperature = 25°C, V
Typical values, RX measured at 10 MHz bandwidth, TX 1 RB at max
Table 51. RF antenna interface LTE/5G NR
Conditions
LTE 2100 Band 1
LTE 1900 Band 2
LTE 1800 Band 3
LTE AWS-1 Band 4
LTE 850 Band 5
LTE 2600 Band 7
LTE 900 Band 8
LTE 700 Band 12
LTE 700 Band 13
LTE 700 Band 14
LTE 700 Band 17
LTE 800 Band 18
LTE 800 Band 19
LTE 800 Band 20
LTE 1900 Band 25
72 Wireless Specifications
Implementation
3GPP Rel 15
FR1 (Sub 6G): n41, n77, n78, n79: 26 dBm +2/–3 dB all other bands: 23 dBm ±2 dB
FDD: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25, B26, B28, B29, B30,
B32, B66, B71 TDD: B34, B38, B39, B41, B42, B48 LAA: B46 (DL only)
For supported carrier aggregations (CA)
B1, B2, B3, B4, B7, B25, B30, B66, B38, B41, B42, B48
all LTE bands
UE Cat. 13 (UL: 150 Mbps) + UE Cat. 20 (DL: 2 Gbps); 7xDL CA, 3xUL CA (Intra-band), 5xDL
CA+4X4 MIMO (Up to UE Cat20)
B41: 26 dBm +2/–3 dB all other bands: 23 dBm ±2 dB
Bd.I, Bd.II, Bd.IV, Bd.V (Bd.VI, Bd.XIX), Bd.VIII, Bd.IX
all 3G bands
DC-HSPA+ - DL Cat. 24 (42 Mbps) / UL Cat. 6 (11 Mbps) HSUPA - UL 5.76 Mbps
Compressed mode (CM) supported according to 3GPP TS25.212
all bands: 24 dBm +1.7/–3.7 dB
3V3
Tx PRx
23.3 –97
23.2 –97
23.9 –97
23.5 –97
23.2 –99.5
23.4 –97
23.7 –99.5
23.5 –99.5
23.1 –100
23.4 –99.5
23.2 –100
23.9 –99.5
23.3 –99.5
23.9 –99.5
23.7 –97
= 3.3 V
DRx PRX MIMO
–97.5 –97.5
–97 –97
–97 –97
–98 –97.5
a
–101
–97.5 –97
a
–100.5
a
–100.5
a
–100
a
–100
a
–100
a
–100.5
a
–101
a
–100.5
–96.5 –97.5
DRX MIMO Unit
–97.5 dBm
–97.5 dBm
–97.5 dBm
–97 dBm
a
dBm
–96.6 dBm
a
dBm
a
dBm
a
dBm
a
dBm
a
dBm
a
dBm
a
dBm
a
dBm
–97 dBm
