Topics:
•

Overview

•

Features

•

Packing list

• Optional accessories
Overview
The Dell EMC Edge Gateway 5200 fanless embedded computing platform, incorporating Intel
SATA trays, one M.2 2280 drive (when the 5G module is not in use), one Mini PCIe slot, and access for I/O ports, optimizes
easy maintenance in industrial automation environments. Compact size and robust design make the EGW-5200 a perfect fit
for adapting to versatile application scenarios. The series supports DDR4 memory for powerful computing and the Intel
Graphics 630 speeds graphics performance. The fanless construction overcomes contaminant and noise challenges presented
by harsh industrial automation environments, and the elimination of problematic structural elements that negatively affect MTBF
greatly increases lifecycle expectations for the platform.
Features
®
● 9th Generation Intel Core™ i7/i5/i3 FCLGA1151 processor and C246 chipset
● 2x DDR4 SO-DIMM socket, supporting up to 32 GB DDR4 per socket, for a total of 64 GB
● 2x DisplayPort, 1x DVI-D, and 1x VGA, supporting three independent displays
● 6x external USB ports (2x USB 3.1 Gen 2, 1x USB 3.1 Gen 1, 3x USB 2.0), one internal USB 2.0 port
● Three Intel GbE LAN ports
● Built-in 8-ch DI and 8-ch DO, two software-programmable RS-232/422/485 + two RS-232 ports
● Built-in wide-range 12 V DC to 24 V DC power input
● WiFi 6E
● Optional uFM modules to extend functionality with isolated 2x COM (RS-422/485), 2x COM (RS-232), 2x GbE with PoE, 2x
GbE LAN, 2x Canbus, 4G, 5G, and 8x DI/O modules
Packing list
Before unpacking, check the shipping carton for any damage. If the shipping carton or contents are damaged, inform your
dealer immediately. Retain the shipping carton and packing materials for inspection. Obtain authorization from your dealer before
returning any product to Dell Technologies. Ensure that the following items are included in the package.
● EGW-5200 fanless embedded computer
● EGW-5200 Setup Guide
● Safety, Environmental, Regulatory, and Legal Information document
● Accessory box
○ DC power jack
○ Wall-mount brackets
○ Screw pack
○ Antennas
