6.5 Streaming RTP

Once you have UDP streaming running, it is relatively simple to change to RTP streaming. All that is
needed is a change of settings and an SDP file (an example file is provided with the software release
from Z3). To stream using RTP, complete the following steps:
(17) Click on "Stop Encoder" to stop the current encoding session.
(18) Verify "Output Interface" is "Ethernet (VBR)".
(19) Change "Output Format" from "MPEG-2 TS" to "RTP".
*Note: Be sure not to select "MPEG-2 TS over RTP".
(20) Confirm that "Dest Port" is 8888- This will be important for the VLC configuration.
(21) Click on "Start Encoder" to start the RTP encoding session.
Once you finish, your settings should match the following:
(1) Click "Stop Encoder"
If encoder was running

Figure 13 Changes to Encoding Parameters for RTP Encode

____________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N. 8th St. STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
(5) Click "Start
Encoder"
15
DOC-USR-0080-01
(2) Change Output
Interface to
"Ethernet(VBR)"
(3) Change Format to
"RTP"
(4) Confirm "Dest Port"
is 8888
