(9) Click on the Z3-MVE-10 entry in the window to select it. This will cause the "Edit Device," "Open
Device" and "Flash LEDs" boxes to activate:
(10) By clicking "Edit Device," you can change the Name, IP Address, Netmask and Gateway address of
the Z3-MVE-10. You can also flash the LEDs on the Z3-MVE-10 by clicking "Flash LEDs" (this is useful
if there are multiple Z3-MVE-10's connected). Click on "Open Device." An internet browser window
is opened (default browser used is Firefox) and the Web GUI appears:
____________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N. 8th St. STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702

Figure 7 ZFinder with Z3-MVE-10 Selected

Figure 8 The Z3-MVE-10 Web GUI (Top Portion)

11
DOC-USR-0080-01
