(3) Open VLC. Select "Open Network Stream." If the settings are those as shown in Figure 26, use the
address "udp://@225.1.2.3:8888" (see
(4) In VLC, select "Subtitle – Sub Track – Closed Caption 1". This configures VLC to use the extracted
closed caption data that the encoder has extracted and encoded. You should then see the subtitles
on the screen:
(2) Subtitles start to appear

Figure 27 Setting VLC to use the Extracted Closed Caption Data

(5) Extraction of closed caption through SDI input is also possible. In that case, SDI In of the Z3-MVE-10 is
used. The procedure for seeing the closed caption data through VLC is the same as shown above.
____________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N. 8th St. STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
Figure 11
(1) Select "Subtitle – Sub Track – Closed Caption 1"
26
on page 14).
