8.0 PERFORMING OTHER OPERATIONS WITH THE Z3-MVE-10

8.1 Saving Current Settings

If you have a specific configuration you would like to preserve, you can save it so that when the
Z3-MVE-10 is powered off and turned back on, it automatically uses those settings. This can be done with
the following steps:
(1) Once you make a change you want to save, click on "Save User" at the bottom of the configuration
menu [This option is available in both encode and decode modes]:
Click "Save User" to
save current settings

Figure 33 The "Save User Settings" Button

When you reboot the Z3-MVE-10, encode will automatically start with the saved settings.
31
