Z3 Technology Z3-MVE-10 User Instructions page 37

D1 Sharpness
(For Composite Input
Only)
Output Interface
Output Format
Dest Address
Dest Port
TS Bit Rate
PID Audio, Video,
PCR
Stop Encoder
[Button]
Start Encoder
[Button]
Status
Note 1: Encoder Resolutions Supported:
1080i (1920x1080), 3/4 1080i (1440x1080), XGA (1280x1024), 720p (1280x720), 4/5 720p
(1024x720), D1 NTSC (720x480), D1 PAL (720x576), 4-CIF (704x576), VGA (640x480) 2-CIF (352x576),
CIF (352x288), SIF (352x240), QVGA (320x240), WQVGA (320x180)
____________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N. 8th St. STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
0-2
Ethernet (VBR)
ASI
ASI+Ethernet (CBR)
RTP
MPEG-2 TS
MPEG-2 TS RTP
RTMP
x.y.z.w (225.1.2.3)
0 – 9999 (8888)
0 – 20Mbps (12Mbps)
0 – 999 (120, 220, 520)
-----
-----
Idle, Stopped, Running
Controls the peak and coring filters of the
analog front end for D1. 0 is a normal (flat)
setting. 2 causes the highest sharpness
gain. The encoder will encode more
efficiently with less sharp pictures. If the
bitrate is high, this can be used to enhance
the picture quality. The general
recommendation is to leave this at 0.
Selects where bit stream is output
(Ethernet, ASI, or both).
*Note: RTP can only be streamed over
Ethernet.
Output format of encoded stream.
*Note: RTP requires an SDP file for the
receiver.
"MPEG-2 TS RTP" sends a stream
encapsulated with MPEG-2 TS within an RTP
transport stream.
See "Streaming RTMP" for details on using
RTMP .
The IP address that the encoder is
streaming to.
The port that the encoder is streaming to.
Only appears for "MPEG-2 TS" and "MPEG-2
TS RTP" Output Formats. The overall bit
rate for the generated transport stream. A
margin of 30-50% over the video bit rate for
high bit rates is recommended.
The PIDs assigned to audio, video, and the
PCR in the TS stream. Values are separated
by a space.
Stop current encode session.
Start encode session.
Current status of the encoder.
37
DOC-USR-0080-01
