6.6

Streaming RTP

Once you have UDP streaming, it is relatively simple to change to RTP streaming. All that is needed is a
few parameter changes. To stream using RTP, do the following steps:
(17) In the CH1 configuration tab, click on "stop" to stop the current encoding session.
(18) Change "Output Format" from "UDP" to "RTP."
(19) Click on "start" to start the RTP encoding session. At this point your settings will look like the
following:
___________________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N 8
Figure 12 Channel 1 Configuration Screen – RTP
th ST, STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
(1) Change to "RTP"
16
DOC-USR-0027-10
