(5) Power on the Z3-MVE-10:
(1) Turn on PWR
(6) Wait around one minute for the "Status" LED to light up.

6.3 Finding the Z3-MVE-10 on the Network using ZFinder

ZFinder is a PC Utility that allows you to find any Z3 product on your network. If you have not
downloaded this to your computer, you can find it on the flash drive provided with your system.
(7) Verify your Windows PC is connected to the same network the Z3-MVE-10 is connected to.
(8) Run the "ZFinder" PC Utility on your Windows PC. The ZFinder window appears. ZFinder then
completes a scan of the network and lists the location of all Z3 systems connected to the network.
In this case, the Z3-MVE-10 appears:
____________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N. 8th St. STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702

Figure 5 Z3-MVE-10 Power Switch and Status Light

Figure 6 ZFinder with Z3-MVE-10 Listed

(2) Status lights up after around 1 minute
