Accelnet Plus Micro Modules User Guide
M B P
OTOR RAKE
The brake output is an open-drain MOSFET with internal flyback diode for driving inductive
loads. It can sink up to 1A from a motor brake connected to the +24 Vdc supply. The operation
of the brake is programmable with CME. It can also be programmed as general-purpose digital
output (shown in the table below).
Pin Signal
1 +24V_IN
2 BRAKE
3 HVCOM
S
PECIFICATIONS
Output
Voltage Range
Output Current
H /L D
I O EFINITIONS
Input State
LO
BRAKE
[OUT3]
HI
AEV, APV
The EZ brake circuit is referenced to HVCOM and SGND in the AEZ, APZ.
Copley Controls
D
IN ESCRIPTIONS
Function
+24V Input
Brake Output
HVCOM
Data Notes
Max +30 Vdc
Ids 1.0 Adc
: O
UTPUTS
Condition
Output MOSFET Q3 is
OFF. Brake is un-powered
and locks motor. Motor
cannot move. Brake state
is Active
Output MOSFET Q3 is ON.
Brake is powered,
releasing motor. Motor is
free to move. Brake state
is NOT-Active
5V
O U T 3
SG N D
CME Default Setting for rake Output OUT3 is " rake - Active ow"
Active = Brake is holding motor shaft (i.e. the Brake is Active)
Motor cannot move
No current flows in coil of brake
CME I/O Line States shows [OUT3] as LO
BRK Output voltage is HI (24V), MOSFET Q3 is OFF
Servo drive output current is zero
Servo drive is disabled, PWM outputs are off
Inactive = Brake is not holding motor shaft (i.e. the Brake is Inactive)
Motor can move
Current flows in coil of brake
CME I/O Line States shows [OUT3] as HI
BRK output voltage is LO (~0V), MOSFET Q3 is ON
Servo drive is enabled, PWM outputs are on
Servo drive output current is flowing
AEZ, APZ 10
2 V I N
A E
3
.7
10k
V C O M
16-01687 Rev 03
rake
2 V
0
Page 63 of 139
