Accelnet Plus Micro Modules User Guide
3 S
PECIFICATIONS
A A
GENCY PPROVALS
Specification
Approvals
Functional Safety
Electrical Safety
Machinery
EMC
Markings
Hazardous
Substances
I P
NPUT OWER
+HV is required for operation of the drives. VLOGIC is optional for supply voltages <= 60
Vdc and powers the communications, feedback, and I/O functions but not the PWM outputs.
VLOGIC is recommended for drives operating on a control network because it enables the
network master to maintain communication with the drives when the +HV has been
removed, most commonly for safety or EMO (Emergency Off) conditions.
AEV-090-14
Specification
APV-090-14
+HV Voltage
+HV Current
14
Peak *
+HV Time
Peak (sec)
+HV Current
7
Cont.
VLOGIC Vdc
VLOGIC
Power **
* The actual +HV current is dependent on the input voltage and motor load and operating conditions.
The Maximum +HV currents shown above occur when the drive is operating from the maximum input voltage and is
producing the rated continuous output current at the maximum output voltage. Unit is Adc.
** VLOGIC supply current depends on the number of encoders connected to the drive.
The maximum current draw given assumes that the encoder +5V output is loaded to 500mA Unit is Vdc
Copley Controls
Requirement
UL and cUL recognized component to UL 61800-5-1
UL Functional Safety to IEC 61800-5-2,
EMC to IEC 61800-3
IEC 61508-1, IEC 61508-2, IEC 61508-3, EN (ISO) 13849-1,
ISO 13849-2, IEC 61800-5-2.
Directive 2014/35/EU – Low Voltage, UL 61800-5-1:2016
Directive 2006/42/EC
Directive 2014/30/EU
IEC 61800-3:2017, Category C3
Label is visible on PC board
Lead free and RoHS compliant
AEV-090-30 AEV-090-50
APV-090-30 APV-090-50
+9 to +90 Vdc
30 50
15 25
4 W with no encoders, 6.6 W with two encoders, +5V @ 500 mA
AEV-090-50-C AEZ-090-50
APV-090-50-C APZ-090-50
50 50
1
50 25
+9 to +60
16-01687 Rev 03
AEZ-090-50-C AEV-180-10
APZ-090-50-C APV-180-10
+20 to +180 Vdc
50 10
50 5
AEV-180-20
APV-180-20
20
10
