Accelnet Plus Micro Modules User Guide
M B C
OTOR RAKE
AEZ Brake Connector Locations
Top View
Brake Receptacle
Description
Manufacturer PN
Brake Cable Plug
Description
Manufacturer PN
Wire Size
Recommended Wire
Connectors and contacts are included in Connector Kits AEV-EZ-CK, APV-EZ-CK
Connector Tools
Note: This part is shown here for convenience. It is not included in connector kits,
and is not sold by Copley Controls.
Description
Contact Extraction tool for contacts
Pin Descriptions
EZ Board J10
Pin Signal
1 +24V_IN
2 BRAKE
3 HVCOM
Copley Controls
ONNECTOR
APZ models have the same
connector numbers as the AEZ
models shown here.
EZ B
OARD
Male receptacle, 2.0 mm, 3-position
Hirose Electric: DF3-3P-2DSA(01)
Locking, 2.0 mm, 3-position, pluggable female receptacle.
Hirose Electric: DF3-3S-2C
28~22 AWG
28~22 AWG, 600 V
Shielded cable required for CE compliance
EZ Development Board J10
Function
+24V Input
Brake Output
HVCOM
11 IN
12
OUT
EZ D
Manufacturer & PN
Hirose Electric: DF-C-PO (A)
Pin Signal Function
1 +24V_IN +24V Input
2 BRAKE Brake Output
3 HVCOM HVCOM
16-01687 Rev 03
5 13
1
3
S 1
2
S 2
17
B
EVELOPMENT OARD
6
P1
10
