Accelnet Plus Micro Modules User Guide
5 C
ONNECTIONS AND
The AEZ-090-50 and APZ-090-50 models consist of modules soldered into EZ boards to make a single assembly able to output
the maximum rated 50 A currents. AEV and APV drives can plug into the same EZ boards with the exception of the 50 A models
which must be soldered to achieve their rated output currents.
Model AEV-EZ-090, AEV-EZ-180, APV-EZ-090 and APV-EZ-180 EZ boards are not compatible with and must
! not be used with the AEV-090-50, AEV-090-50-C, APV-090-50 or APV-090-50-C Accelnet Micro Module
models. Refer to models AEZ-090-50, AEZ-090-50-C, APZ-090-50 and APZ-090-50-C instead.
Failure to heed this warning may cause equipment damage or injury
P C
OWER ONNECTOR
P E
ROTECTIVE ARTH
Top View
P E
ROTECTIVE ARTH
Data
Description
Manufacturer PN
P E
ROTECTIVE ARTH
Data
Wire size
Recommended Wire
Wire Insertion/Extraction Tool
Copley Controls
W
IRING
L EZ B
OCATIONS
APV models have the same
connector numbers as the AEV
models shown here.
EZ B
OARD
R
ECEPTACLE
EZ Board J14
Screw connection, 6.35 mm, 2-position,
terminal block
Phoenix Contact: 1714955
W
IRING
EZ Board J14
22~10 AWG
22~10 AWG, 600 V
Shielded cable required for CE
compliance
Slotted screwdriver
– EZ B
OARDS
M
OARD ODELS
11 IN
12
OUT
EZ D
EZ Development Board J17
Push-in CAGE CLAMP, 10 mm, 7-position,
terminal block
Wago: 2616-3107/020-000
EZ Development Board J17
18~4 AWG
18~4 AWG, 600 V
Shielded cable required for CE
compliance
Tool not required.
16-01687 Rev 03
.
5 13 6
1
3
S 1
2
S 2
17
B
EVELOPMENT OARD
P1
10
Page 55 of 139
