Accelnet Plus Micro Module Models - Copley Controls Accelnet Plus AEV-090-14 User Manual

Accelnet Plus Micro Modules User Guide
A P
CCELNET
Network
EtherCAT
CANopen
Ic = Continuous Output Current, Adc (peak of sine)
Ip = Peak Output Current, Adc (peak of sine)
+HV = Power supply voltage for PWM outputs to motors (DC, line-isolated)
VLOGIC = Power supply for the drives control circuits and external encoder +5 Vdc
* AEZ-090-50 is an AEV-090-50 soldered into an AEV EZ Board
APZ-090-50 is an APV-090-50 soldered into an APV EZ Board
** AEZ-090-50-C is an AEV-090-50-C soldered into an AEV EZ Development Board
APZ-090-50-C is an APV-090-50-C soldered into an APV EZ Development Board
Copley Controls
M M
LUS ICRO ODULE
Models
AEV-090-14
AEV-090-30
AEV-090-50
AEZ-090-50 *
AEV-090-50-C
AEZ-090-50-C **
AEV-180-10
AEV-180-20
APV-090-14
APV-090-30
APV-090-50
APZ-090-50 *
APV-090-50-C
APZ-090-50-C **
APV-180-10
APV-180-20
M
ODELS
Ic Ip +HV
7 14
15 30
25 50 9~90
50 50
5 10
20~180
10 20
7 14
15 30
25 50 9~90
50 50
5 10
20~180
10 20
16-01687 Rev 03
VLOGIC
9~60
